Rotel A10 MKII Integrated Amplifier (Silver)

Regular price $599.00
Sale price $599.00 Regular price
Save $-599.00 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Mon, Feb 17 – Mon, Feb 24
Other Options

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Rotel A10 Overview

Product Information

Model: A10M2S | UPC: 672563260112

Specifications

What's In The Box

Product Information

Model: A10M2S | UPC: 672563260112

The Rotel A10MKII Integrated Amplifier is a meticulously engineered audio component designed to enhance your music listening experience. Delivering 50 watts per channel of Class A/B power into 8-ohm speakers, it ensures robust and clear sound reproduction. With three line-level RCA inputs and a Moving Magnet Phono stage, it accommodates a variety of analog sources, including vinyl turntables. The front panel features user-friendly controls for bass, treble, and balance adjustments, complemented by an included IR remote control for convenient operation. Available in black and silver finishes, the A10MKII combines power, versatility, and style for discerning audiophiles.

Features

  • Powerful Class A/B Amplification
  • Versatile Connectivity Options
  • User-Friendly Controls
  • High-Quality Headphone Output
  • Elegant Design

Powerful Performance

At the heart of the A10MKII is a substantial Rotel-built toroidal transformer, providing a solid foundation for its 50 watts per channel output into 8-ohm loads, with increased power available for more demanding speakers. This design ensures dynamic and accurate audio playback, bringing your music to life.

Versatile Connectivity

The amplifier offers three line-level RCA inputs, allowing seamless connection to various analog devices. Additionally, the built-in Moving Magnet Phono stage caters to vinyl enthusiasts, enabling direct connection of turntables without the need for an external preamp.

User-Friendly Controls

The front panel is thoughtfully arranged with rotary controls for bass, treble, and balance, making real-time sound adjustments straightforward. A motorized analog volume control provides precise level adjustments, and the included IR remote enhances convenience from a distance.

Private Listening Option

For personal listening sessions, the A10MKII includes a front-panel 1/8” headphone jack equipped with a dedicated amplifier circuit, ensuring high-quality audio output through your headphones.

Elegant Design

Available in sleek black or silver finishes, the A10MKII's aesthetic complements its high-performance capabilities, making it a stylish addition to any audio setup.

Specifications

  • Total Harmonic Distortion: < 0.03%
  • Intermodulation Distortion: < 0.03% (60 Hz : 7k Hz, 4:1)
  • Frequency Response
  • Phono input: 20 Hz - 20k Hz, -0.5 dB, +0.3 dB
  • Line Level Inputs: 10 Hz - 100k Hz, -0.5 dB, +0.05 dB
  • Damping Factor: 120 (20 - 20,000 Hz, 8 Ohms)
  • Input Sensitivity / Impedance
    • Phono input: 1.5 mV / 43k Ohms
    • Line Level Inputs: 120 mV / 45k Ohms
  • Input Overload
    • Phono input: 50 mV
    • Line Level Inputs: 4 V
  • Tone Controls - Bass / Treble: ± 6 dB at 100 Hz / 10k Hz
  • Signal to Noise Ratio (IHF “A” weighted)
  • Phono input: 85 dB
  • Line Level Inputs: 90 dB
  • Power Requirements: 120 V, 60 Hz
  • Power Consumption: 150 Watts
  • Standby Power Consumption: < 0.5 Watts
  • BTU (4 Ohms, 1/8 power): 450 BTU/h
  • Dimensions (W x H x D): 17” x 2 7/8” x 13 5/8”
  • Front Panel Height: 2-3/8”
  • Weight: 14.5 lbs.

What's In The Box

  • A10 MKII Integrated Amplifier
  • Power Cord
  • Remote
  • Manual
