Theory Audio Design sb25 High-Output Surface Mount Loudspeaker - Each

Regular price $1,095.00
Sale price $1,095.00 Regular price
Save $-1,095.00 (%)
This item is only available in our showroom. Call 215-368-8343 for details.

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Theory sb25 Overview

Product Information

Model: SB25-BK | UPC: 850014164003

Specifications

What's In The Box

Product Information

Model: SB25-BK | UPC: 850014164003

The sb25 by Theory Professional is a compact yet powerful loudspeaker designed to deliver exceptional audio quality in various settings. Its versatility makes it an ideal choice for venues such as restaurants, bars, hotels, retail stores, and houses of worship, where both background and foreground sound clarity are essential.

Features

  • High-Performance Sound in a Compact Design
  • Wide 125-Degree Conical Sound Coverage
  • Durable Aluminum Construction
  • Flexible Mounting Options
  • Powerful Output for Professional Use

Compact Design with Powerful Performance

Despite its slim profile of just 3.8 inches in depth, the sb25 doesn't compromise on performance. Equipped with two 5-inch carbon fiber low-frequency drivers and a 1.4-inch advanced polymer high-frequency compression driver, it offers a wide frequency range from 54Hz to 23kHz (-6dB), ensuring rich and detailed sound reproduction.

Wide and Uniform Sound Coverage

The sb25 provides a 125-degree conical coverage pattern, ensuring consistent audio dispersion across a broad area. This wide and uniform dispersion guarantees that every listener experiences high-fidelity sound, regardless of their position relative to the speaker.

Robust Build Quality

Constructed with a powder-coated and anodized extruded aluminum enclosure, the sb25 is built to last. Its durable design ensures reliable performance in various indoor environments, making it a dependable choice for professionals seeking both quality and longevity in their audio equipment.

Flexible Mounting Options

The sb25 features two Theory VersaSlot™ T-slots running the full height of the enclosure, along with four M5 captive nuts, providing flexible mounting solutions. Optional accessories, such as the Universal Mount Adapter and Table Top Stand, further enhance its adaptability, allowing for seamless integration into diverse installation scenarios.

Specifications

  • Description: Compact Surface Mount Multipurpose High Output Loudspeaker System
  • Operation: Passive, Requires 1 Theory Loudspeaker Controller Amp Channel
  • DSP Requirements: Requires Model-Specific Theory-Certified DSP Loudspeaker Processing
  • Drivers
    • 2 x 5" Theory Carbon Fiber Low Frequency Drivers
    • 1 x 1.4" Theory Advanced Polymer High Frequency Compression Driver
  • Enclosure: Powder Coated and Anodized Extruded and Machined Aluminum, Fabric Grille
  • Terminals: Twin Spring-Loaded Push Terminals
  • Outdoor Capability: Indoor Use Only
  • Mounting Points: Two Theory VersaSlotTM T-Slots Running Full Height with 4 x M5 Captive Nuts
  • Optional Universal Mount Adapter, and Table Top Stand
  • Bandwidth
    • 54Hz -23kHz, -6dB;
    • 46Hz-24kHz, -10dB
  • Coverage: 125 Degrees Conical
  • 160 Degrees Conical (-12dB @ 10kHz)
  • Sensitivity: 94dB (LF); 108dB (HF) SPL/2.83V/1m
  • Power Handling
    • 200W (AES);
    • 400W (Continuous);
    • 800W (Peak)
  • Minimum Recommended Power: 50W rms
  • Maximum Output
    • 117dB / 1m (based on AES power rating)
    • 123dB SPL / 1m (peak)
  • Nominal Impedance: 4-ohms
  • Dimensions (W x H x D): 9.5" x 21.5” x 3.8"
  • Total Installed Depth with Z-clip Mount: 3.93"
  • Net Weight: 23 lbs.

What's In The Box

  • sb25 High-Output Surface Mount Loudspeaker
  • Z-Clip Mounting Brackets
  • Manual
