SVS SoundPath Balanced XLR Audio Cable - 6.56 ft. (2m) - Pair

Regular price $89.00
Sale price $89.00 Regular price
Save $-89.00 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Tue, Dec 3 – Tue, Dec 10

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: SPXLR2M | UPC: 850029050070

Specifications

What's In The Box

Product Information

Model: SPXLR2M | UPC: 850029050070

Cables should never be the weakest link in your system, nor should they cost more than your speakers and components. Through inspired engineering for world-class performance, SVS SoundPath Balanced XLR Audio Cables ensure signal purity, a secure connection, and rejection of interference from the innovative five-layer shielding system.

Available in lengths from 1 to 15 meters, SoundPath XLR cables are fit for the finest Class A amplifiers, preamps, subwoofers, pro audio gear, and other line-level components.

Features:

  • Available in 1, 2, 3, 5, 8 12, and 15 meter lengths
  • 24K gold plated conductor pin for pure, stable connection
  • Five-layer isolation system rejects noise and electromagnetic interference (EMI)
  • Red and white marking for Left/Right channel designation
  • Protective cotton braided jacket for easy gripping and management
  • Work with preamps, power amplifiers, subwoofers, AV receivers, microphones, and other audio components with balanced XLR inputs and outputs

Inspired Engineering for World-Class Performance

Premium build materials and rigorous testing under extreme conditions ensure your system always sounds its best with SVS SoundPath Balanced XLR Audio Cables. Three-dimensional imaging, unveiled highs, neutral midrange, and tight, articulate bass.

  • Highly conductive cold-fused gold plating on all electrical contacts in both terminals
  • Three dedicated multi-strand high-purity conductors for superior connection integrity
  • Heavy-duty directionally connected 56-strand outer shield for resistance to RFI sources
  • Professional grade cast Zinc-Alloy terminals with black nickel-plating
  • Red and White marking bands for easy Left and Right designation
  • Densely braided easy-grip cotton jacket forms the fifth layer of RFI shield
  • Lockable, push-button release terminal clips ensure a secure connection

Specifications

  • Cable Construction Materials
    • Tri-balanced high gauge 99.99% oxygen-free-copper conductors individually isolated in independent HDPE dielectric jackets for consistent flow, high purity, and minimal signal loss
    • 1.6mm HDPE inside core dielectric – the first of the five-layer insulation system shields twisted trio of dedicated conductors
    • Aluminum wrap shield – the second layer in the shielding and insulation system
    • 56-strand spiral braid of 99.99% OFC tinned copper soldered to chassis ground terminal forms a critical third barrier in the five-layer insulation system to remove EMI and RF noise between electronics
    • High-density PVC jacket wrapped in densely braided cotton jacket provides flexibility, and easy gripping, and forms the final two layers in the five-layer insulation system
    • Five-layer isolation system rejects electromagnetic interference (EMI)
  • XLR Connector Construction Materials
    • Precision-soldered with high-grade lead-free solder to ensure durable and constant electrical contacts with consistent signal flow
    • 24K gold-plated brass conductor pin for stable electrical contact and signal flow
    • Solid zinc-alloy terminal with black nickel plating provides stylish and durable body with comfortable handling
    • Red and white marking bands for easy left and right channel designation
    • Shield layer is hand-soldered to source terminal chassis connection for the best possible grounding and noise rejection
  • Electrical Properties
    • Conductor DCR = 77 mΩ/meter
    • Shield DCR: 40 mΩ/meter
    • Nominal Impedance: 110Ω. Cable and XLR connectors are impedance-matched to minimize Voltage Standing Wave Ratio (VSWR) and Return Loss
    • Nominal Capacitance: 39 pF/meter @ 1kHz
    • Rated Bandwidth: DC-5.0 MHz (3M cable) with ≤1.09 VSWR and ≥27dB Return Loss

What's In The Box

  • 2x Balanced XLR Audio Cable - 2m
