Sumiko Songbird High MC Cartridge

Regular price $899.00
Sale price $899.00 Regular price
Save $-899.00 (%)
OR

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: 844682009308 | UPC: 844682009308

Specifications

Product Information

Model: 844682009308 | UPC: 844682009308

The Songbird comes in at a much needed price point perfect for launching the part-time audiophile into some serious listening. As its name suggests, this open-architecture moving coil cartridge excels at providing colorful and rich vocals, and highlights the powerful low and mid-end of funk and rock. The long 7-micron stylus face will handle different cutting angles well, and this cartridge is also great at providing some excitement to otherwise anemic classical system setups.

Specifications

  • Cartridge Type: Moving Coil
  • Stylus: 0.3 x 0.7 micron Elliptical
  • Cantilever Material: coated aluminum pipe
  • Wire Material: pure copper
  • Internal Impedance: 135 Ohms
  • Load Impedance: 47kΩ
  • Frequency Response: 12Hz - 40kHz
  • Output Voltage: 2.5mV
  • Channel Separation: 30dB @ 1kHz
  • Channel Balance: <0.5dB @ 1kHz
  • Compliance: 12x10-6 cm/dyn @ 100Hz
  • Recommended load capacitance: 100pF - 200pF
  • Vertical tracking angle: 20
  • Tracking Force: 1.8g - 2.2g
  • Recommended Force: 2.0g
  • Cartridge Weight: 8.5g
