Home Theater Systems Buying Guide
Product Information
Specifications
Specifications
- Receiver
- Video Input
- HDMI (Front):7(1)
- HDCP2.2 (Front): 6(1)
- HDMI Input supporting HDCP2.2(Front): 6(1)
- HDCP2.2 (Front/Rear): 6/1
- Composite (Front): 2(0)
- Video Output
- HDMI: 2
- HDCP2.2: 2
- HDMI Output supporting HDCP2.2: 2
- Composite Monitor Out: 2
- Audio Input
- Opt: 2
- Coax.: 1
- Analog Audio In: 4
- Audio Output
- Pre-Out (Front (L/R)): Yes
- Pre-Out (Center): Yes
- Pre-Out (Surround(L/R)): Yes
- Pre-Out (Surround Back(L/R): Yes
- Pre-Out (Height1(L/R)): Yes
- Pre-Out (Height2(L/R)): Yes
- Pre-Out (Subwoofer): 2
- S-Center out: Yes
- Input/Output Others
- Bluetooth Receiver: Yes
- Bluetooth Transmitter: Yes
- Wi-Fi: Yes
- USB: 1
- USB Front(ver) / Rear(ver): 1/0
- Ethernet Port (Power over Ethernet): 1(0)
- Ethernet Port (Power over Ethernet Plus): 1(0)
- Wireless speakers option: Yes
- Speaker Out
- Front A: Yes
- Center: Yes
- Surround: Yes
- Surround Back(Front B/Bi-AMP/Zone 2): Yes
- Height 1: Yes
- Height 2 (Zone 2/Center 2(R Only)): Yes
- Number of amp. channels: 13ch
- Front: 150W + 150W (8ohms, 1kHz, THD 0.9%)
- Center: 150W (8ohms, 1kHz, THD 0.9%)
- Surround: 150W + 150W (8ohms, 1kHz, THD 0.9%)
- Surround Back: 150W + 150W (8ohms, 1kHz, THD 0.9%)
- Hight1: 150W + 150W (8ohms, 1kHz, THD 0.9%)
- Hight2: 150W + 150W (8ohms, 1kHz, THD 0.9%)
- Speaker Impedance: 4ohms-16ohms
- Frequency Characteristics: 10Hz-100kHz ±3dB
- Signal-to-Noise Ratio(A Network)(When all of EQ/Surround off): 105dB(Analog In)
- Audio Features
- Decodable channel number: 13.1ch
- 4 Ohm/8 Ohm Switching: Yes
- OP processing: Yes
- Sub Woofer Low Pass Filter: Yes
- Cross Over Frequency: 17 points(40-200Hz)
- Speaker Selector: A/B/A+B/OFF
- Speaker Terminal Type: Screw (Gold)
- Pure Direct: Yes
- DSD Native Playback: Yes
- 360 Spatial sound mapping: Yes
- Center Speaker Lift Up: Yes
- Acoustic Center Sync: Yes
- Dual Center Speaker: Yes
- In-Ceiling Speaker Mode: Yes
- A/V SYNC: Yes(Variable)
- A/V Sync Time/Sampling Frequency: 0-300msec
- DSEE Ultimate: Yes
- High-Resolution Audio: Yes
- High-Resolution Audio Wireless: Yes
- 360 Reality Audio: Yes
- DCAC Features
- D.C.A.C. IX / D.C.A.C. EX / Advanced D.C.A.C. / D.C.A.C.: D.C.A.C. IX
- Speaker Relocation: Yes
- Phantom Surround Back: Yes
- Automatic Phase Matching: Yes
- Calibration Mic: Stereo
- EQ for D.C.A.C: 31band GEQ
- Tone Control
- Front (Bass / Treble): Yes
- Center (Bass / Treble): Yes
- Surround (Bass / Treble): Yes (Common with Surround Back)
- Surround Back (Bass / Treble): Yes (Common with Surround)
- Height1: Yes
- Height2: Yes
- Sound Field
- 2ch Stereo: Yes
- Direct: Yes
- Dolby Mode: Yes
- DTS:X Mode: Yes
- Auto Format Decoding for Movie: Yes
- Auto Format Decoding: Yes
- Multi Stereo: Yes
- Audio Enhancer: Yes
- Tuner
- Preset Channel (FM/AM): TTL30 (30/0)
- Station Name: Yes
- Auto Tuning: Yes
- Direct Tuning: Yes
- HDMI
- Decoding Formats
- DSD: Yes (Up to 2.8MHz 5.1ch)
- LPCM: Yes (Up to 192kHz/24 bit 7.1ch)
- LPCM 96kHz/24bit: Yes
- LPCM 192kHz/24bit: Yes
- DTS HD MA / DTS HD HR: Yes/Yes
- Dolby TrueHD/Dolby Digital Plus: Yes/Yes
- DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes
- Dolby Digital EX / Dolby Digital: Yes/Yes
- DTS 96/24: Yes
- DTS:X: Yes
- Dolby Dual Mono: Yes
- Dolby Atmos: Yes
- Video Features
- HDMI Video Output capability 8K, 4K, 1080p, 1080/24p, Deep Color (up to 36 bit), Triluminous Color (xvYCC)
- 8K 60 Support: Yes (HDMI IN1,2,3,4)
- 4K 120 support Yes(HDMI IN1,2,3,4)
- 4K 60p 4:4:4 Support Yes
- Video Up Scaler: Yes (2K24/50/60p, 4K24/50/60p, up to 8K)
- 3D over HDMI: Yes
- HDR: Yes (HDR10, Hybrid Log Gamma, Dolby Vision)
- IMAX Enhanced: Yes
- Audio Features
- Audio Return Channel: Yes
- eARC: Yes
- ARC without CEC control: Yes
- Others
- BRAVIA® SYNC™ (CEC Control): Yes (System Audio Control, System Power Off, RC Pass Through, Language Follow, One-Touch Play)
- Standby Through: Yes
- Features for PlayStation(R)5
- Auto HDR Tone Mapping Compatible (Pass-Through): Yes
- Auto Genre Picture Mode Compatible (Pass-Through): Yes
- USB Type A
- USB Mass Storage
- Interface: Yes
- DSD: Yes (11.2MHz 2ch, 5.6MHz 5.1ch)
- LPCM: Yes
- DSDIFF(DSD): Yes
- DSF: Yes
- WAV(LPCM): Yes
- AIFF(LPCM): Yes
- FLAC: Yes
- ALAC: Yes
- WMA: Yes
- MP3: Yes
- AAC: Yes
- Walkman Connectivity
- Music/Video/Photo: Yes/-/-
- Network Features
- Network Player/Renderer: -/Yes
- DSD: Yes (11.2MHz 2ch, 5.6MHz 5.1ch)
- LPCM: Yes
- DSDIFF(DSD): Yes
- DSF: Yes
- WAV(LPCM): Yes
- AIFF(LPCM): Yes
- FLAC: Yes
- ALAC: Yes
- WMA: Yes
- MP3: Yes
- Network Renderer: Yes
- DLNA Party Streaming: Yes
- AirPlay2: Yes
- Spotify Connect: Yes
- Music Center compatible: Yes
- Music Center compatible models with iPod/iPhone/iPad: Yes
- SongPal Link: Yes
- Chromecast built-in: Yes
- Works with the Google Assistant: Yes
- Works with SONOS: Yes
- Roon tested: Yes
- Installation
- Zone Features
- 2nd A: Speaker(Variable) / Line (Variable, Fixed) / HDMI(Fixed)
- 2nd V: HDMI / Composite(monitor)
- 3rd A: Line (Variable, Fixed)
- Multi Zone Line Out Level Control (Zone2/Zone3): Yes (Yes/Yes)
- Digital Audio D/A distribution to Zone: Yes (Zone2 source)
- Coaxial/Opt Audio D/A distribution to Zone: Yes (Zone2)
- HDMI Audio for Zone Down Mix: Yes for Source, No for the other input
- Control Features
- IR Repeat (In/Out): Yes (1/2)
- RS-232C for control: Yes
- CIS IP Control: Yes
- 12V Trigger: 3
- Controller Connectivity
- Certification (Crestron/Control4/Savant): Yes/Yes/Yes
- SDDP(Control4): Yes
- Certification (AMX/Crestron/Control4): No/Yes/Yes
- Crestron Connected: Yes
- OvrC (Control4): Yes
- Domotz: Yes
- Josh AI: Yes
- System Setting
- Setting Save / Load by USB: Yes
- Setting Lock: Yes
- Others
- UI
- GUI: Yes
- GUI Blending: Yes
- GUI Language: EN/FR/ES/DE/JP
- Easy Setup Wizard: Yes
- Customize Features
- Custom Preset (Easy Automation): Yes
- Input Assign (HDMI/Component/Opt/Coax): Yes (Yes/-/Yes/Yes)
- General
- Pin Jack: Gold
- Heat Sink: Aluminum
- Detachable AC: Yes
- Power Requirement: 120V 60Hz
- Power Consumption: 540W
- Power Consumption(Standby): 0.5W
- Power Consumption(Network/BLUETOOTH Standby): 3.5W
- Auto Standby: Yes
- Remote Commander: RMT-AA511U
- Attachment: Calibration microphone, Calibration mic stand, FM wire antenna, AC power cord, Remote control, R03 (size-AAA) batteries, Front cover
- System Update (Internet/USB/PC): Yes (Yes/Yes/-)
- Weight and Measurements
- Receiver Dimensions (W x H x D): 17 x 7 ¾” x 17 3/8”
- Receiver Weight: 48lb
- Gross Weight: 55lb 13oz
- Language
- Quick Setup Guide: English, Spanish, French
- Instruction Manual: English, Spanish, French
- Help Guide: English, Spanish, French
What's in the Box
What’s in the Box
- STR-AZ7000ES 13.2 Channel 8K Home Theater AV Receiver with Dolby Atmos, DTS: X, IMAX Enhanced, Google Assistant, & Works with Sonos
- Calibration Microphone with Stand
- FM Antenna
- Remote Control
- Remote Control Batteries
- Power Cord
- Manual
Reviews
Customer Reviews for Sony STR-AZ7000ES 13.2 Channel 8K Home Theater AV Receiver with Dolby Atmos, DTS: X, IMAX Enhanced, Google Assistant, & Works with Sonos
Q&A
Customer Q & A
Have a functionality, compatibility, or otherwise product-specific question about this product? Ask it here! If you have a customer service or shipping question, please direct it to our customer service department
Check the connection between each speaker and the unit.
Adjust the speaker level.
Measure the distance of each speaker from your seating position. (*1)
Measure the speaker size. (*1)
Measure the frequency characteristics (EQ). (*1)
Measure the frequency characteristics (Phase). (*1)(*2)
IX, the latest auto-calibration technology developed by Sony, can correct the distance, angle, sound pressure and frequency response of each speaker by measuring the speaker placement in 3D using the supplied calibration microphone. This works alongside Auto Phase Matching which aligns the phase of different speakers.
