Sony

Sony STR-AN1000 7.2 Channel 8K Home Theater AV Receiver with Dolby Atmos, DTS: X, IMAX Enhanced, Google Assistant, & Works with Sonos

Regular price $698.00
Sale price $698.00 Regular price
$899.99 Save $201.99 (22%)
OR

Limited time offer! Sale ends 4/21/2024.
In Stock & Ready to Ship
Free Shipping Get it between Tue, Apr 23 – Tue, Apr 30

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: STRAN1000 | UPC: 027242924031

Specifications

What's In The Box

Product Information

Model: STRAN1000 | UPC: 027242924031

Bring the Theater Home

Experience breathtaking 8K video and immersive 3D audio with Sony's new 7.2-channel 8K receiver. Enjoy space-filling sound from your 7.2 or 5.2.2 setup with Dolby Atmos® and DTS:X.®  It’s easy to enjoy all your content with Works with SONOS, Chromecast Built-in, Apple AirPlay®, and Spotify Connect—all via Wi-Fi or Bluetooth®.

Features

  • 7.2-channel A/V Receiver (165 W 6 ohms, 1kHz,  THD 0.9%)
  • 8K & 4K/120 HDMI Connectivity with HDMI 2.1 support (6-in/2-out)
  • Supports Dolby Atmos® & DTS:X® object-based sound decoding
  • Immersive audio with Digital Cinema Auto Calibration IX and 360 Spatial Sound Mapping
  • Supports today’s leading HDR formats: Dolby Vision, HDR10, Hybrid Log Gamma, and IMAX Enhanced.
  • “Works With Sonos” makes it possible to integrate the STR-AN1000 with your new or already existing Sonos  system
  • Stream your way with Bluetooth®, Wi-Fi, Chromecast built-in, Spotify Connect, and Apple AirPlay®
  • Connects to your home’s other devices with Google Assistant
  • Sets up easily with a graphical interface that walks you through each step
  • Zone 2 & Zone 3 for Flexible, multi-zone distribution capability
  • Center channel enhancements include Center Speaker Lift Up and Acoustic Center Sync
  • Control with Sony Music Center app
  • Compatible with Sony’s SA-RS3S & SA-RS5 wireless rear speakers and SA-SW3 & SASW5 wireless subwoofers

Step Up Your Sound

With 165 watts, the STR-AN1000 delivers cinema-like surround sound and crystal-clear music reproduction with powerful amplification.

8K & 4K/120 HDMI Connectivity

Enjoy the latest HDMI technology with support for 8K & 4K/120 video sources. Equipped with two 8K HDMI inputs and two outputs, the STR-AN1000 is capable of delivering the most stunning picture quality and amazing clarity.

Support for the Most Advanced Object-Based Audio Formats

With support for Dolby Atmos®, Dolby Speaker Virtualization, DTS:X®, and DTS Virtual: X the STR-AN1000 delivers an object-based surround sound experience.

360 Spatial Sound Mapping

Experience true immersion. Sony’s exclusive 360 Spatial Sound Mapping technology reproduces a physical sound field that can adapt to your environment so your home theater feels more like a cinema or concert hall.

Digital Cinema Auto Calibration IX

A new technology developed by Sony, Digital Cinema Auto Calibration IX precisely corrects the distance, angle, sound pressure, and frequency response of each speaker that’s connected to the STR-AN1000 to create the ideal sound field for any home theater setup.

Supports Dolby Vision®, HDR10, and Hybrid Log Gamma, and IMAX® Enhanced

Enjoy dynamic, realistic picture quality with support for the leading HDR formats, including Dolby Vision®, HDR10, Hybrid Log Gamma, and IMAX® Enhanced.

“Works with Sonos”

After a simple setup, your Sony A/V Receiver will tie in seamlessly to SONOS.  From the SONOS app you will be able to turn on your A/V Receiver, switch to the designated input source for playback, and control the volume of your A/V Receiver.

Easy Listening

Listen to all your favorite tracks, easily. The STR-AN1000 supports audio streaming via Bluetooth®, Wi-Fi, Chromecast built-in, Spotify Connect, and Apple AirPlay® 2.

Voice Assistant Compatibility

Connect to your home’s other devices and use voice control to operate your receiver with Google Assistant.

Roon Tested

Enjoy seamless integration with your Roon system for full access to all your music—including your digital files and streaming services—all in one place.

Compatible with Sony Music Center App

Control the STR-AN1000 from your mobile device for operations like source selection, zone control, sound field control, volume control, media playback, and voice assistant setup.

Center Speaker Lift Up and Acoustic Center Sync

Enhance your sound multiple ways: Center Speaker Lift Up raises the sound from the center speaker to match what’s on the TV, and Acoustic Center Sync matches the audio to your compatible BRAVIA TV.

Easy Setup and Operation

The easy-to-use graphical interface makes it super simple to start enjoying your STR-AN1000.

Zone 2 & Zone 3

Zone 2 & Zone 3 for Flexible, multi-zone distribution capability.

Wireless Speaker & Subwoofer Compatibility

Sony’s SA-RS3S & SA-RS5 wireless rear speakers and SA-SW3 & SA-SW5 wireless subwoofers are compatible with the STR-AN1000. Two subwoofers of the same model may be connected simultaneously to the receiver.

DSEE Ultimate

Using AI-based technology, DSEE Ultimate accurately upscales audio to near-high-resolution sound quality, simulating a recording studio or concert environment.

HDMI 2.1

While enabling higher-quality video output and reduced latency from input devices like game consoles, HDMI 2.1 also provides support for Auto Low Latency Mode (ALLM) and Variable Refresh Rate (VRR).

6 HDMI Inputs / 2 Outputs

The STR-AN1000 has six HDMI inputs with two inputs supporting full 8K & 4K/120 video sources, and two HDMI outputs that also support full 8K & 4K/120 video sources.

Chassis and Sub-Chassis

With the addition of a sub-chassis structure on the rear of the front panel, the rigidity of the receiver is increased. This results in a further reduction of vibration and improved sound quality overall.

Power Supply Capacitors

The newly designed power supply capacitors, developed by Sony, improve stability and achieve superior sound quality.

New Large Capacity Power Transformer

The redesigned power transformer also features a new core material and bobbin to lower distortion and improve sound quality.

Redeveloped Digital Section

The new digital section enables all signal processing to be performed on a single chip while also providing lower impedance, increased capacitance, and better stability.

New DAC Enables 32-bit Operations

Digital PCM signal input is processed at 32-bit and converted to analog by the DAC, while DSD signal input during direct mode is natively input to the DAC and converted to an analog signal.

Improved Analog Power for DAC

The DAC analog power supply uses a low-noise power supply IC to ensure that hi-fidelity performance is achieved.

Buffer Amp for DAC

A new DAC analog output filter circuit was designed utilizing a JFET and op-amp improvement in noise floor. The phase rotation was shifted to a higher frequency, expanding the bandwidth and improving sound clarity for wide-bandwidth sources like high-resolution audio.

Sony Exclusive Pre-Amp Integrated Circuit

A Sony-exclusive integrated circuit was developed to improve all amplification functions of the STR-AN1000.

Hi-Res Audio & 360 Reality Audio

Enjoy music the way the artists truly intended with High-Resolution Audio for crystal clear precision or discover a new way of listening with 360 Reality Audio for a truly immersive live concert or studio session experience.6 With the STR-AN1000, your music comes to life like never before.

Specifications

  • Receiver
    • Video Input
      • HDMI (Front): 6(0)
      • HDCP2.2 (Front): 6(0)
      • HDMI Input supporting HDCP2.2(Front): 6(0)
      • HDCP2.2 (Front/Rear): 0/6
      • Composite (Front): 2(0)
    • Video Output
      • HDMI: 2
      • HDCP2.2: 2
      • HDMI Output supporting HDCP2.2: 2
      • Audio Input
      • Opt: 1
      • Coax.: 1
      • Analog Audio In: 4
    • Audio Output
      • Headphone Out: Yes
      • Pre-Out (Subwoofer): 2
      • S-Center out: Yes
    • Input/Output Others
      • Bluetooth Receiver: Yes
      • Bluetooth Transmitter: Yes
      • Wi-Fi: Yes
      • USB: 1
      • USB Front(ver) / Rear(ver): 1/0
      • Ethernet Port (Power over Ethernet): 1(0)
      • Ethernet Port (Power over Ethernet Plus): 1(0)
      • Wireless speakers option: Yes
    • Speaker Out
      • Front A: Yes
      • Front B: Yes (Common with Surround Back)
      • Center: Yes
      • Surround: Yes
      • Surround Back: Yes
      • Height: Yes (Common with Surround Back)
      • Bi-AMP: Yes (Common with Surround Back)
      • Zone3: Yes (Common with Surround Back)
      • Surround Back/Height (Front B/Bi-AMP/Zone 3): Yes
    • Output Power
      • Number of amp. Channels: 7ch
      • Front: 165W (6ohms, 1kHz, 1ch driven THD 0.9%)
      • Center: 165W(6ohms, 1kHz, 1ch driven THD 0.9%)
      • Surround: 165W(6ohms, 1kHz, 1ch driven THD 0.9%)
      • Surround Back: 165W(6ohms, 1kHz, 1ch driven THD 0.9%)
      • Speaker Impedance: 6ohms-16ohms
      • Frequency Characteristics: 10 Hz - 100 kHz, +0.5/-2 dB
      • Signal-to-Noise Ratio(A Network)(When all of EQ/Surround off): 105dB(Analog In)
    • Audio Features
      • Decodable channel number: 7.1ch
      • OP processing: Yes
      • Sub Woofer Low Pass Filter: Yes
      • Cross Over Frequency: 17 points(40-200Hz)
      • Speaker Selector: A/B/A+B/OFF
      • Speaker Terminal Type: Screw
      • Pure Direct: Yes
      • DSD Native Playback: Yes
      • 360 Spatial sound mapping: Yes
      • Center Speaker Lift Up: Yes
      • Acoustic Center Sync: Yes
      • In-Ceiling Speaker Mode: Yes
      • A/V SYNC: Yes (Variable)
      • A/V Sync Time/Sampling Frequency: 0-300msec
      • DSEE Ultimate: Yes
      • High-Resolution Audio: Yes
      • High-Resolution Audio Wireless: Yes
      • 360 Reality Audio: Yes
    • DCAC Features
      • D.C.A.C. IX / D.C.A.C. EX / Advanced D.C.A.C. / D.C.A.C.: D.C.A.C. IX
      • Speaker Relocation: Yes
      • Phantom Surround Back: Yes
      • Automatic Phase Matching: Yes
      • Calibration Mic: Stereo
      • EQ for D.C.A.C: 31band GEQ
    • Tone Control
      • Front (Bass / Treble): Yes
      • Center (Bass / Treble): Yes
      • Surround (Bass / Treble): Yes (Common with Surround Back)
      • Surround Back (Bass / Treble): Yes (Common with Surround)
      • Height1: Yes
    • Sound Field
      • 2ch Stereo: Yes
      • Direct: Yes
      • Dolby Mode: Yes
      • DTS:X Mode: Yes
      • Auto Format Decoding for Movie: Yes
      • Auto Format Decoding: Yes
      • Multi Stereo: Yes
      • Audio Enhancer: Yes
      • Headphone 2ch: Yes
    • Tuner
      • FM/AM: Yes/No
      • Preset Channel (FM/AM): TTL30 (30/0)
      • Station Name: Yes
      • Auto Tuning: Yes
      • Direct Tuning: Yes
  • HDMI
    • Decoding Formats
      • DSD: Yes (Up to 2.8MHz 5.1ch)
      • LPCM: Yes (Up to 192kHz/24 bit 7.1ch)
      • LPCM 96kHz/24bit: Yes
      • LPCM 192kHz/24bit: Yes
      • DTS HD MA / DTS HD HR: Yes/Yes
      • Dolby TrueHD/Dolby Digital Plus: Yes/Yes
      • DTS / DTS-ES (Matrix6.1 / Discrete6.1): Yes/Yes
      • Dolby Digital EX / Dolby Digital: Yes/Yes
      • DTS 96/24: Yes
      • DTS:X: Yes
      • Dolby Dual Mono: Yes
      • Dolby Atmos: Yes
    • Video Features
      • HDMI Video Output capability: 8K, 4K, 1080p, 1080/24p, Deep Color (up to 36 bit), Triluminous Color (xvYCC)
      • 8K 60 Support: Yes (GAME, MEDIA BOX)
      • 4K 120 support: Yes (GAME, MEDIA BOX)
      • 4K 60p 4:4:4 Support: Yes
      • Video Up Scaler: Yes (2K24/50/60p, 4K24/50/60p, up to 8K)
      • 3D over HDMI: Yes
      • HDR: Yes (HDR10, Hybrid Log Gamma, Dolby Vision)
      • IMAX Enhanced: Yes
    • Audio Features
      • Audio Return Channel: Yes
      • eARC: Yes
      • ARC without CEC control: Yes
    • Others
      • BRAVIA® SYNC (CEC Control): Yes (System Audio Control, System Power Off, RC Pass Through, Language Follow, One-Touch Play)
      • Standby Through: Yes
      • Audio Widget: Yes
  • Features for PlayStation 5
    • Auto HDR Tone Mapping Compatible (Pass-Through): Yes
    • Auto Genre Picture Mode Compatible (Pass-Through): Yes
  • USB Type A
    • USB Mass Storage
      • Interface: Yes
      • DSD: Yes (11.2MHz 2ch, 5.6MHz 5.1ch)
      • LPCM: Yes
      • DSDIFF(DSD): Yes
      • DSF: Yes
      • WAV(LPCM): Yes
      • AIFF(LPCM): Yes
      • FLAC: Yes
      • ALAC: Yes
      • WMA: Yes
      • MP3: Yes
      • AAC: Yes
    • Walkman Connectivity
      • Music: Yes
      • Video: No
      • Photo: No
  • Network Features
    • Network Player/Renderer: -/Yes
    • DSD: Yes (11.2MHz 2ch, 5.6MHz 5.1ch)
    • LPCM: Yes
    • DSDIFF(DSD): Yes
    • DSF: Yes
    • WAV(LPCM): Yes
    • AIFF(LPCM): Yes
    • FLAC: Yes
    • ALAC: Yes
    • WMA: Yes
    • MP3: Yes
    • Network Renderer: Yes
    • DLNA Party Streaming: Yes
    • AirPlay2: Yes
    • Spotify Connect: Yes
    • Music Center compatible: Yes
    • Music Center compatible models with iPod/iPhone/iPad: Yes
    • Chromecast built-in: Yes
    • Works with the Google Assistant: Yes
    • Works with SONOS: Yes
    • Roon tested: Yes
  • Installation
    • Zone Features
      • 2nd A: HDMI(Fixed)
      • 2nd V: HDMI
      • 3rd A: Speaker(Variable) /  Line (Variable, Fixed)
      • Multi-Zone Volume Control (Zone2/Zone3): Yes (-/Yes)
      • Multi-Zone Line Out Level Control (Zone2/Zone3): Yes (-/Yes)
      • Digital Audio D/A distribution to Zone: Yes (Zone3 Source)
      • Coaxial/Opt Audio D/A distribution to Zone: Yes (Zone3 Source)
      • HDMI Audio for Zone Down Mix: Yes for Source
    • Control Features
      • IR Repeat (In/Out): Yes(1/1)
      • 12V Trigger: 0
  • Others
    • UI
      • GUI: Yes
      • GUI Blending: Yes
      • GUI Language: EN/FR/ES/DE/JP
      • Easy Setup Wizard: Yes
    • Customize Features
      • Custom Preset (Easy Automation): Yes
      • Input Assign (HDMI/Component/Opt/Coax): Yes (-/-/Yes/Yes)
  • General
    • Pin Jack: Nickel
    • Heat Sink: Aluminum (Corrugated)
    • Power Requirement: 120V 60Hz
    • Power Consumption: 240W
    • Power Consumption (Standby): 0.5W
    • Power Consumption (Network/BLUETOOTH Standby): 3.5W
    • Auto Standby: Yes
    • Remote Commander (Controller): RMT-AA511U
    • Attachments: Calibration microphone, Calibration mic stand, FM wire antenna, Remote control, R03 (size-AAA) batteries
    • System Update (Internet/USB/PC): Yes(Yes/Yes/-)
  • Weight and Measurements
    • Receiver Dimension (W x H x D): 17” x 6 ¼” x 13 1/8”
    • Receiver Weight: 20lb 12oz
    • Gross Weight: 26lb 15oz
  • Language
    • Quick Setup Guide: English, Spanish, French
    • Instruction Manual: English, Spanish, French
    • Help Guide: English, Spanish, French

What's In The Box

  • STR-AN1000 7.2 Channel 8K Home Theater AV Receiver with Dolby Atmos, DTS: X, IMAX Enhanced, Google Assistant, & Works with Sonos
  • Calibration Microphone with Stand
  • FM Antenna
  • Remote Control
    • Remote Control Batteries
  • Power Cord
  • Manual
