Sony Mobile XM-S400D GS-Series Ultra-Compact 4-Channel Amplifier

Size & Weight

• Dimensions (W x H x D): 62.6 x 37.3 x 162.8
• Weight: 1.01 lb

Amplifier

• Channel Configuration: 4ch
• High Pass Filter: 120 Hz
• High-Pass Filter Slope: 12 dB/oct
• Low Pass Filter: 120 Hz
• Low-Pass Filter Slope: 12 dB/oct

Rated Output Power, RMS 20 - 20000 Hz

• Max. Channel Configuration at 4 ohm (W) / THD (%): 45 W x 4/1.0%
• Max. Channel Configuration at 2 ohm (W) / THD (%): 45 W x 4/1.0%

Maximum Output Power (1 kHz)

• Max. Channel Power Configuration at 4 ohm: 100 W x 4

General Features

• Frequency Response: 20-20 kHz
• Tolerance: +0.5/-3 dB
• Signal to Noise Ratio: 100 dB
• Total Harmonic Distortion at 1 kHz (%): 0.08%

Details

• CEA Power output: 45 W x 4
• CEA SN Ratio: 83 dBA
• MOSFET: Yes/Yes
• Line In: Input Sensitivity: 1 V/8 V
• Current drain (A) - rated output power at 4 ohm: 15 A
