Rotel A14MKII Integrated Amplifier (Silver)

Regular price $1,699.00
Sale price $1,699.00 Regular price
Save $-1,699.00 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Wed, Oct 16 – Wed, Oct 23
Other Options

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Rotel A14 Overview

Product Information

Model: FR01766 | UPC: 672563766114

Specifications

What's In The Box

Product Information

Model: FR01766 | UPC: 672563766114

The A14 MKII Integrated Amplifier delivers Class AB amplification from your favorite sources including analog, digital, PC-USB with MQA, wireless aptXTM and AAC Bluetooth and Moving Magnet Phono stage. Critically tuned power supply, DAC and amplifier circuits ensure the A14MKII will deliver countless hours of entertainment.

Features

  • Certified Roon Tested
  • Supports MQA and MQA Studio
  • Class AB Power
  • Moving Magnet Phono Input for Turntable Connection

Texas Instruments 32-bit/384kHz DAC

A fully redesigned Digital to Analog circuit topology utilizes a Texas Instruments 32-bit/384kHz DAC with exhaustive tuning and hand selection of all critical components delivering a fuller, richer and more balanced presentation of the music. Improvements to the power supply and amplifier gain stages further refine the audio whether you are listening to a big band orchestra or a solo vocalist.

Tone Controls

Tone controls provide treble and bass adjustments in 1dB steps up to +/- 10dB personalizing your experience for all music genres, moods and settings with a BYPASS mode eliminating unwanted noise and distortion.

Sources

The A14MKII supports your favorite sources including analog, digital, PC-USB with MQA, high-quality wireless aptX™ and AAC Bluetooth streaming and even a Moving Magnet Phono stage for vinyl fans.

Roon Tested

The A14MKII is certified Roon Tested delivering the best experience using Roon software so you can just enjoy the music. Control system integration is available utilizing Ethernet, RS232, 12V-Trigger and remote IR connections.

5-Way Speaker Binding Posts

Dual 5-way speaker binding posts allow Zone 2 installations with relay-controlled selection of the A-B speaker outputs.

Display

The front panel graphic display includes a large volume indication and audio stream information.

Specifications

  • Dimensions (W × H × D): 17" × 3.6" × 13.5"
  • Front Panel Height: 3.15"
  • Power Requirements: 120V, 60Hz
  • Power Consumption: 280W
  • Standby Power Consumption: <0.5W
  • Net Weight: 19.71lbs.
  • BTU Rating (4O, 1/8th power): 632 BTU/h
  • Total Harmonic Distortion (THD): <0.018%
  • Frequency Response
  • Line Level Inputs: 10Hz - 100kHz, 0±0.5dB
  • Digital Inputs: 10Hz - 90kHz, 0±2.0dB
  • MaxPhono Input: 20Hz - 20kHz, 0±0.5dB
  • S/N Ratio (IHF "A" Weighted)
  • Line Level Inputs: 100dB
  • Digital Inputs: 103dB
  • Phono Input: 90dB

What's In The Box

  • A14MKII Integrated Amplifier
  • Power Cord
  • Manual
