Product Information

Model: FONOMC | UPC: 5056186700727

The Fono MC has been designed to be effective, easy to use, and above all, to reproduce music. Rega’s Fono MC Phono Stage boosts the ultra-low signal of a moving-coil cartridge to match the line-level inputs of any modern amplifier, preamp, or powered speakers.

Linear Systems

The Fono MC uses the Linear Systems low noise LSK389 FET in an all discrete input stage where low noise and linearity are vitally important to get the best from an MC cartridge. Because of the high input impedance of FET, the loading effects of the amplifier circuit are minuscule and do not affect the performance of the cartridge.

MUSE Amplifier

A MUSE operational amplifier is used in the RIAA equalization amplifier. Polypropylene capacitors have been used in the signal path and in the RIAA equalization circuits. There is selectable input loading for both resistance and capacitance along with two different gain settings located on the back panel making the Fono MC compatible with most low output MC cartridges.

Design

The aesthetic design of the Fono MC was as important as the quality of its electrical capabilities, so it benefits from the same aluminum case as the Rega TTPSU and Fono MM amplifier, giving it a design which offers a familiar feel and moreover brings it in line with its illustrious bigger brothers. The new Fono MC circuit resulted from the design work carried out on the Aria phono amplifier.

Specifications

  • Output impedance: 200Ω
    • Recommended minimum output load resistance: 5K
    • Frequency response (50KΩ output load): 13Hz (-3dB) to 100KHz (-0.3dB)
    • RIAA accuracy (50KΩ output load): Better than +/-0.2dB 100Hz to 100KHz
    • Power requirements: 24V AC at 150mA maximum. Only to be used with Rega PS1.
  • Input sensitivity (for 200mV output)
    • 4 off: 133uV
    • 4 on: 67uV
  • Input loading resistance
    • 1 and 2 off: 400Ω
    • 1 on: 100Ω
    • 2 on: 150Ω
    • 1 and 2 on: 70Ω
  • Input loading capacitance
    • 3 off: 1000pF
    • 3 on: 4300pF
    • Gain (at 1KHz)
    • 4 off = 63.5dB
    • 4 on = 69.5dB
  • Maximum input level (at 1KHz)
    • 4 off: 6.7mV
    • 4 on: 3.4mV
  • Load settings for adjustable MC stages
    • Impedance: 100 ohm
    • Capacitance: 1000pF
    • Gain setting: High ('On' position for Rega phono stages)
  • General
    • Dimensions (W x H x D): 15.7" x 3" x 7.4"
    • Weight: 2.75 lbs

What's In The Box

  • Fono Moving Coil Phono Stage
  • Power Cord
  • Manual
