Panamax M4315-PRO 8 Outlet Power Conditioner & Surge Protector

Now on demo at:

1 of 4

Panamax M4315-PRO 8 Outlet Power Conditioner & Surge Protector

Regular price $749.00
Sale price $749.00 Regular price
$1,073.78 Save $324.78 (30%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Tue, Sep 15 – Tue, Sep 22
Man with brown hair and beard wearing glasses and a gray button-down shirt

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781
Sad face plus music note equals happy face graphic

Panamax M4315-PRO Overview

Product Information

Model: M4315-PRO | UPC: 050616008594

Specifications

What's In The Box

Product Documents

Product Information

Model: M4315-PRO | UPC: 050616008594

The Nice M4315-PRO features the revolutionary Panamax® AVM (Automatic Voltage Monitoring) circuit, and exclusive Linear Filtering Technology (LiFT). Together, these technologies comprise precisely what our customers have come to expect: uncompromising AC protection and purification. Outlets: all eight (8) rear panel outlets are separately controlled. They are grouped into four (4) filter-isolated banks. BlueBOLT™ is included, providing secure, hosted IP system control and monitoring for the M4315-PRO.

Features

  • BlueBOLT IP Power Management
  • Individually Controllable Rear Outlets
  • Linear Filtering Technology
  • Automatic Voltage Monitoring
  • Protect-Or-Disconnect Circuitry
  • Four Isolated Filter Banks

Specifications

  • General
    • Family: Pro Series
    • Line Voltage: 120 (Volts)
    • Number of Outlets: 9
    • Number of Isolated Banks: 4
    • Rack Mountable: Yes
    • Rack Ears Included: Yes
    • Voltage Regulation: No
    • Compliance: cCSAus
  • Outlet Configuration
    • Outlet Description: 1 (always on, linearly filtered outlet, front panel)
    • Outlet Description: 6 (individually switchable, linearly filtered outlets)
    • Outlet Description: 2 (individually switchable, high current outlets)
  • Front Panel & Control
    • Front Panel Meter(s): Volts/Amps Combo Meter
    • Front Media Light(s): No
    • Control: Full outlet control using BlueBOLT or Telnet commands. Limited outlet control through front panel buttons or rear panel DC trigger.
    • Low Voltage Trigger: 12V In
  • Power Cord
    • AC Power Cord: 10 ft. detachable
  • Dimensions & Weight
    • Dimensions (W x H x D): 19″ W (17″ without rack ears) x 1.75″ H x 12.25″ D
    • Weight: 12 lbs
  • AC Protection
    • Voltage Protection Rating (UL 1449 3rd Edition, 3,000A): 500V
    • Single Pulse Energy Dissipation: 2700 Joules
    • Peak Impulse Current: 135,000 Amps
    • AC Protection Technology: Protect or Disconnect
    • AC Protection Technology: Automatic Voltage Monitoring
    • AC Protection Technology: L-N, L-G, N-G Protection Modes
    • AC Protection Technology: Thermal Fusing
    • Under-Voltage Shutoff: 100 VAC ± 2 VAC
    • Over-Voltage Shutoff: 134 VAC ± 2 VAC
    • Maximum Current Rating: 15 (Amps)
    • Initial Clamping Level: 200V Peak
  • Filtration
    • Filtration Technology: LiFT
    • Filtration Rating – Banks 1, 2, 3: 76db, 5KHz – 250 kHz
    • Filtration Rating – Bank 4 High Current Outlets: 46 db, 250 KHz – 1 Mhz
  • LAN Protection
    • LAN – Wires Protected: 8-Wires
    • LAN – Compatibility: 10/100/1000 BASE-T
    • LAN – Clamping Level: 60 ± 5V
  • Coax Protection
    • Coax – Shielded: Yes
    • Coax – Insertion Loss: < 0.5 dB
    • Coax – HD 1080 i/p Ready: Yes
    • Coax – Frequency Range: 0 MHz – 2.2 GHz
    • Coax – Connections: Female “F”, Gold Plated
    • Coax – Clamping Level: 75V
    • Coax – Bidirectional: Yes
  • Signal Line Protection
    • Signal Line Protection: 1 LAN
    • Signal Line Protection: 1 Tel
    • Signal Line Protection: 2 Cable/Satellite

What's In The Box

  • M4315-PRO 8 Outlet Power Conditioner & Surge Protector
  • Power Cord
  • Manual
