• Black moving coil phono cartridge with a silver metal body and exposed stylus tip

Ortofon SPU Classic N Moving Coil Cartridge (Black)

✕

Now on demo at:

1 2
ORTOFON

Ortofon SPU Classic N Moving Coil Cartridge (Black)

$1,037.99
$1,037.99
$0.00 Save $-1,037.99 (%)
OR
World Wide Stereo 60-Day Returns World Wide Stereo Price Match Guarantee
Man with brown hair and beard wearing glasses and a gray button-down shirt

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781
Sad face plus music note equals happy face graphic

Overview

Product Information

Model: SCLASSICN | UPC: 5705796240221

Specifications

What's In The Box

Product Information
Model: SCLASSICN | UPC: 5705796240221

The SPU Classic N is a Moving Coil (MC) cartridge with an 18µm spherical stylus profile that provides the same sound reproduction properties as the SPU Classic GM series.

Listeners who wish to mount the SPU Classic on a traditional headshell may do so by using an SPU N adaptor.

Note: The SPU Classic N is sold without the integrated headshell unit.

Specifications
  • Output voltage at 1kHz, 5cm/sec.: 0.2mV
  • Channel balance at 1kHz: <1dB
  • Channel separation at 1kHz: >20dB
  • Channel separation at 15kHz: >10dB
  • Frequency response: 20Hz - 20kHz ±3dB
  • Tracking ability at 315Hz at recommended tracking force: 65μm
  • Compliance, dynamic, lateral: 8μm/mN
  • Stylus type: Nude spherical
  • Stylus tip radius: R 18μm
  • Tracking force range: 3.0g - 5.0g (30 - 50mN)
  • Tracking force, recommended: 4.0g (40mN)
  • Tracking angle: 20º
  • Internal impedance, DC resistance: 2.5 ohm
  • Recommended load impedance: > 10 ohm
  • Coilwire material: High purity copper
  • Cartridge weight: 13g

What's In The Box
  • SPU Classic N Moving Coil Cartridge
