Ortofon SPU Classic N E Moving Coil Cartridge (Black)

✕

Now on demo at:

1 2
ORTOFON

Ortofon SPU Classic N E Moving Coil Cartridge (Black)

$1,163.99
$1,163.99
$0.00 Save $-1,163.99 (%)
OR
World Wide Stereo 60-Day Returns World Wide Stereo Price Match Guarantee

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781

Overview

Product Information

Model: SCLASSICNE | UPC: 5705796240238

Specifications

What's In The Box

Product Information
Model: SCLASSICNE | UPC: 5705796240238

The SPU Classic NE is a Moving Coil (MC) cartridge with an elliptical stylus profile that provides more detailed sound reproduction and expansive imaging. Listeners who wish to mount the SPU Classic NE on a traditional headshell may do so by using the SPU N adaptor.

Note: The SPU Classic NE is sold without the integrated headshell unit.

Specifications
  • Output voltage at 1kHz, 5cm/sec.: 0.2mV
  • Channel balance at 1kHz: <1dB
  • Channel separation at 1kHz: >20dB
  • Channel separation at 15kHz: >10dB
  • Frequency response: 20kHz - 20kHz +3/-2dB
  • Tracking ability at 315Hz at recommended tracking force: 65μm
  • Compliance, dynamic, lateral: 8μm/mN
  • Stylus type: Nude elliptical
  • Stylus tip radius: r/R 8/18μm
  • Tracking force range: 3.0g - 5.0g (30 - 50mN)
  • Tracking force, recommended: 4.0g (40mN)
  • Tracking angle: 20º
  • Internal impedance, DC resistance: 2.5 ohm
  • Recommended load impedance: > 10 ohm
  • Cartridge body material: High purity copper
  • Cartridge weight: 13g

What's In The Box
  • SPU Classic N E Moving Coil Cartridge
