Ortofon MC Cadenza Bronze Moving Coil (Bronze)

Now on demo at:

1 of 2

Ortofon MC Cadenza Bronze Moving Coil (Bronze)

Regular price $2,599.99
Sale price $2,599.99 Regular price
$0.00 Save $-2,599.99 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Thu, Jul 30 – Thu, Aug 6

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781

Overview

Product Information

Model: MCCADENZABRONZE | UPC: 5705796230130

Specifications

What's In The Box

Product Information

Model: MCCADENZABRONZE | UPC: 5705796230130

Conveying Music with Supreme Precision, Impact, and Dynamics

The Cadenza Bronze model uses a Replicant 100 stylus and a conical aluminum cantilever, and the coil wire is the famous Ortofon Aucurum wire, which is a gold-plated 6NX copper wire. A specialized Field Stabilizing Element/FSE is used for optimal linearity especially during complex crescendo passages. The Cadenza Bronze stereo imaging capabilities illuminate the farthest corners of the soundstage in all three dimensions.

The people at Ortofon are constantly looking for new technology to be used in their products and push the performance of existing technology. Thus they assure the highest level of performance and quality. The Kontrapunkt models and MC Jubilee became market standards and are among their most popular cartridges. Nevertheless, Ortofon decided to develope a new cartridge series that is even more ambitious.

By carefully implementing cobalt-iron pole pieces, new and improved winding process on the armature, and using extruded aluminum housing in the models as well as other changes, Ortofon has been able to reveal new possibilities in performing the analogue information. It was also decided to make a more complete range of cartridges, which meant an introduction of a moving coil Cadenza Mono model to support customers who have an extended interest in micro groove mono records.

Specifications

  • Output voltage at 1kHz, 5cm/sec.: 0.4mV
  • Channel balance at 1kHz: <1dB
  • Channel separation at 1kHz: >24dB
  • Channel separation at 15kHz: >20dB
  • Frequency range at -3dB: -20Hz - 55kHz
  • Frequency response: 20Hz - 20kHz +/-1/5
  • Tracking ability at 315Hz at recommended tracking force: 80μm
  • Compliance, dynamic, lateral: 12μm/mN
  • Stylus type: Nude Ortofon Replicant on conical alu cantilever
  • Stylus tip radius: r/R 5/100
  • Tracking force range: 2.2g - 2.7g (22 - 27mN)
  • Tracking force, recommended: 2.5g (25mN)
  • Tracking angle: 23º
  • Internal impedance, DC resistance: 5 ohm
  • Recommended load impedance: 50 - 200 ohm
  • Cartridge body material: Stainless steel/aluminum
  • Cartridge weight: 10.7g

What's In The Box

  • MC Cadenza Bronze Moving Coil (Bronze)
