McIntosh

McIntosh MC830 1-Channel Solid-State Monoblock Power Amplifier

Regular price $4,500.00
Sale price $4,500.00 Regular price
Save $-4,500.00 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Thu, Apr 18 – Thu, Apr 25

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: MC830 | UPC: 842548109957

Specifications

What's In The Box

Product Information

Model: MC830 | UPC: 842548109957

Features

  • The MC830 is a 1-Channel Solid State Amplifier that features an open chassis industrial design similar to the popular MC275 Vacuum Tube Amplifier, C8 Vacuum Tube Preamplifier, and MA252 and MA352 Integrated Amplifiers.
  • Direct coupled output design that is rated at 300 Watts at 8 Ohms or 480 Watts at 4 Ohms.
  • Fast-responding Dual Scale Watt meter gives an accurate readout of power output for both speaker impedances.
  • Monogrammed Heatsinks™ add visual appeal and will keep the MC830 running cool for optimum performance.
  • Power Guard® technology monitors the output signal to protect your speakers against being overdriven.
  • Sentry Monitor™ technology monitors the output current and shuts the amplifier off if it ever exceeds safe limits.
  • Solid Cinch™ speaker binding posts easily secure your speaker cables to prevent them from coming loose and possibly causing a short.
  • Power Control ports allow for easy system power up and shut down by sending power on/off signals to other connected McIntosh components.
  • User selectable Auto-Off feature will turn off the MC830 after 30 minutes if no audio signal is received.

Specifications

  • Electronic Specifications
    • Power Output per Channel:
      • 300 Watts into 8 Ohms
      • 480 Watts into 4 Ohms
    • Number of Channels: 1
    • Total Harmonic Distortion: 0.005%
    • S/N below rated output:
      • Balanced: 120dB
      • Unbalanced: 118dB
    • Dynamic Headroom: 2dB
    • Damping Factor: >100 Wideband
    • Rated Power Band: 20Hz to 20kHz
    • Frequency Response
      • +0, -0.25dB from 20Hz to 20,000Hz
      • +0, -3.0dB from 10Hz to 100,000Hz
  • Control
    • Remote Power Control: Yes
    • Multi-Channel DB25 Cable: N/A
  • Connectivity
    • Speaker Binding Post Type: Patented Solid Cinch™ Speaker Binding Posts
  • General Specifications
    • Circuit Configuration: Push-Pull Complementary
    • Circuit Design: Solid State
    • Mono Bridge: N/A
    • Mono Parallel: lN/A
    • Output Type: Direct Coupled
    • Meters: Yes
    • Meter Light Switch: Yes
    • Balanced Input: 1
    • Front Panel: Glass
    • Illumination: Direct LED
    • Chassis Style: Polished Stainless Steel
  • Weights & Dimensions
    • Dimensions (W x H x D): 12-9/32" x 9-1/2" x 16"
    • Weight: 48 lbs

What's In The Box

  • Remote
  • Manual
