McIntosh MA352 Integrated Amplifier

Regular price $7,000.00
Sale price $7,000.00 Regular price
Save $-7,000.00 (%)
Add-ons
McIntosh ... For the Love of Music... (Hardcover Book)
McIntosh ... For the Love of Music... (Hardcover Book)
$150.00
Learn More
This item is only available in our showroom. Call 215-368-8343 for details.

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: MA352 | UPC: 842548109117

Specifications

Product Information

Model: MA352 | UPC: 842548109117

The MA352 Integrated Amplifier is a hybrid design that combines the finest of vacuum tube and solid-state audio design principles. The result is an eye-catching amplifier that enjoys the best of these two opposing audio philosophies all while reproducing music at the highest quality level.

An all-analog design, the MA352 has a vacuum tube preamplifier section that is powered by a pair of 12AX7A and a pair of 12AT7 vacuum tubes; its output stage is a direct coupled solid-state amplifier that outputs 200 Watts per channel into 8 Ohm speakers or 320 Watts per channel into 4 Ohm speakers – enough power to properly drive virtually any set of loudspeakers. Dual scale blue Watt meters give an accurate readout of power output for both speaker impedances.

The MA352 has 2 balanced and 3 unbalanced inputs plus 1 Moving Magnet phono input with adjustable loading for connecting a turntable. It has gold-plated speaker binding posts to help prevent corrosion and ensure a quality signal is sent over your speaker cables to your speakers. A stereo preamplifier output is available for connecting a higher-powered amplifier; it can also be used to connect 1 or 2 powered subwoofers for added low-frequency performance.

The MA352 is packed with numerous McIntosh technologies including:

  • Patented Power Guard® technology that monitors the output signal for over driving and makes real-time micro-adjustments to the input signal to prevent harsh sounding clipping that could potentially damage your speakers
  • Fuse-less short-circuit protection circuit Sentry Monitor™ that will disengage the output stage before current exceeds safe operating levels and then resets automatically when operating conditions return to normal
  • McIntosh Monogrammed Heatsinks™ which are connected to advanced high current output transistors that minimize thermal equilibrium lag (or warm-up) time
  • High Drive headphone amplifier with Headphone Crossfeed Director (HXD®)
  • 5-band analog tone control allows for manual adjustment of your favorite recordings (each band adjustable by ± 12dB)
  • Home Theater Pass Through lets it be seamlessly integrated into a home theater system
  • Power Control to send power on/off signals to connected McIntosh components for easy system power up and shutdown
  • Data Ports to send remote control commands to connected source components

Specifications

  • Power output per channel
    • 200W into 8 ohms
    • 320W into 4 ohms
  • Number of channels: 2
  • Speaker impedance: 4 or 8 ohms
  • Rated power band: 20Hz to 20kHz
  • Total harmonic distortion: 0.03%
  • Dynamic headroom: 1.5dB
  • Frequency response
    • 0, -0.5dB 20Hz to 20kHz
    • +0, -3dB 10Hz to 100kHz
  • Sensitivity phono (Moving Magnet): 2.5mV
  • Sensitivity high level (Balanced/Unbalanced): 0.5V/0.25V
  • Signal to noise ratio
    • Moving magnet: 82dB
    • High level: 93dB
  • Input impedance (Balanced/Unbalanced): 20K/20K
  • Damping factor
    • 8 ohms: >200
    • 4 ohms: >100
  • Maximum output (Balanced/Unbalanced): 8V unbalanced
  • Balanced input: 2
  • Unbalanced input: 3
  • Phono input moving magnet: 1 (fixed loading)
  • Unbalanced Variable Output: 1
  • Headphone output: 1/4" high drive
  • Subwoofer Output: 2
  • Home Theater Passthrough: Yes
  • Unbalanced analog connector type: Standard
  • Speaker binding post type: Standard
  • Tone controls: 5-band
  • Tone bypass and input assign: Yes
  • RS232 control input: Yes
  • Power control output: 1
  • Rear panel data port: 2
  • Rear panel IR Sensor Input: Yes
  • Input level match: Yes
  • Vacuum tube or solid state
    • Preamplifier: Vacuum tube
    • Power amplifier: Solid state
  • Output type: Direct Coupled
  • Output Meters: Yes
  • Dual layer chassis: Yes
  • Chassis finish: Polished stainless steel
  • McIntosh monogrammed heat sinks: Yes
  • Power requirement: 120V 50/60Hz, 6A
  • Standby requirement: <0.5W
  • Dimensions (W x H x D): 17 1/2" x 9 7/8" x 20 1/2"
  • Weight: 66 lbs.
