McIntosh MA252 Integrated Amplifier

Model: MA252 UPC: 842548107168 Item: 169931

McIntosh MA252 Integrated Amplifier Overview

McIntosh has combined their famous tube preamp and a quite powerful solid-state power amplifier into one compact and great looking integrated amp in the MA252. The preamp features a low-noise MM PHONO input for vinyl lovers, a Balanced input, and an additional two stereo inputs plus outputs for a powered subwoofer. Bass and treble controls are also included. With 100 Watts per channel into 8-Ohm speakers and 160 Watts per channel into 4-Ohm speakers, the MA252 can easily drive almost any speakers. It’s even fully remote controlled.

Product Information

The MA252 Integrated Amplifier is the first hybrid integrated amplifier from McIntosh. Taking retro design cues from the legendary McIntosh MC275 Vacuum Tube Amplifier, the MA252 combines the best of vacuum tube and solid-state circuit design to create an amplifier that’s both visually and sonically stunning.

The preamplifier stage uses two 12AX7a and two 12AT7 vacuum tubes housed inside stylish protective cages; the output stage is a direct coupled solid-state amplifier that delivers 100 watts per channel into 8 ohm speakers or 160 watts per channel into 4 ohm speakers. An all analog design, it comes with 2 unbalanced, 1 balanced, and 1 Moving Magnet phono input for turntables. All 4 inputs can be given user-friendly names in order to simplify user control. Bass and treble tone controls help fine-tune your music to your personal preferences. A full range subwoofer output is included for use with a powered subwoofer to further enhance low frequencies.

The MA252 features McIntosh Monogrammed Heatsinks, which are connected to advanced high-current output transistors. These transistors eliminate the typical amplifier warm-up time so that the MA252 is in peak operating condition from the moment it’s turned on. A powerful control microprocessor is used for smooth system operation, along with some of the latest audio-grade circuit components that deliver the best possible sound.

Thanks to its solid-state output, the MA252 is McIntosh's first product containing vacuum tubes to include their patented Power Guard technology. Power Guard monitors the output signal for signs of overdriving and makes real-time micro adjustments to the input signal to prevent harsh sounding clipping that could potentially damage your speakers. If Power Guard is activated, the 2 vacuum tubes connected to the affected audio channel(s) will flash an amber color; they will return to their normal green color when the clipping has stopped.

Other McIntosh technologies found in the MA252 include Sentry Monitor, High Drive headphone amplifier and gold-plated speaker binding posts. Input selection, bass, treble, tone bypass, balance, and input offset levels can be adjusted using the front panel knobs or the included remote control; all settings and input selection will be shown on the OLED display. The entire unit sits atop a beautiful polished stainless steel chassis with a classic McIntosh-styled die cast aluminum name badge attached to each side.

Product highlights

  • Retro style that McIntosh tube amplifiers are known for
  • Ultra-low noise and distortion
  • Built-in high-current headphone amplifier
  • McIntosh’s best volume control design for precise adjustment
  • Remote control of all functions including power, volume, mute, tone settings, and channel balance
  • Cool running for long life
  • Warranty: 3 years – World Wide Stereo is an authorized dealer for every brand we sell
  • Included: World Wide Stereo 60-day guarantee and expert product support

Specifications

Specifications

  • Power output per channel
    • 100W into 8 ohms
    • 160W into 4 ohms
  • Number of channels: 2
  • Speaker impedance: 4 or 8 ohms
  • Rated power band: 20Hz to 20kHz
  • Total harmonic distortion: 0.03%
  • Dynamic headroom: 1.8dB
  • Frequency response
    • 0, -0.5dB 20Hz to 20kHz
    • +0, -3dB 10Hz to 100kHz
  • Sensitivity phono (Moving Magnet): 3.0mV
  • Sensitivity high level (Balanced/Unbalanced): 0.6V/0.3V
  • Signal to noise ratio
    • Moving magnet: 80dB
    • High level: 97dB
  • Input impedance (Balanced/Unbalanced): 20K/20K
  • Damping factor
    • 8 ohms: >200
    • 4 ohms: >100
  • Maximum output (Balanced/Unbalanced): 8V unbalanced
  • Balanced input: 1
  • Unbalanced input: 2
  • Phono input moving magnet: 1 (fixed loading)
  • Headphone output: 1/4" high drive
  • Unbalanced analog connector type: Standard
  • Speaker binding post type: Standard
  • Tone controls: Bass and treble
  • Tone bypass and input assign: Yes
  • RS232 control input: No
  • Power control output: 1
  • Rear panel data port: 1
  • Input level match: Yes
  • Vacuum tube or solid state
    • Preamplifier: Vacuum tube
    • Power amplifier: Solid state
  • Dual layer chassis: Yes
  • Chassis finish: Polished stainless steel
  • McIntosh monogrammed heat sinks: Yes
  • Power requirement: 120V 50/60Hz, 3.7A
  • Standby requirement: <0.5W
  • Dimensions (W x H x D): 12" x 7 5/8" x 18"
  • Weight: 28 lbs.

What's in the Box

What's in the Box:

  • MA252 Integrated Amplifier
  • Remote control

Reviews

Customer Reviews for McIntosh MA252 Integrated Amplifier

There are no reviews for this item. Write Review

Q&A

Customer Q & A

Have a functionality, compatibility, or otherwise product-specific question about this product? Ask it here! If you have a customer service or shipping question, please direct it to our customer service department

Start typing your question and we'll check if it was already asked and answered. Learn More
Browse 4 questions Browse 4 questions and 4 answers
will the McIntosh MA252 Integrated Amplifier drive stacked (four) original Advent loud speakers? These are often referred to as wall of sound.
A shopper on Jul 11, 2019
  Yes, it would drive them and sound beautiful.
Will 6 tower speakers rated at 30 to 500 watts work well with this amplifier ?
Pete L on Feb 19, 2019
  Absolutely! This amp would do a wonderful job with your speakers. With the ability to run 4-8 ohm speakers without breaking a sweat, you will get a phenomenal experience with your towers.
will the MA252 drive the old school speakers such as the AR 90s its rated 50wpc min and 300wpc max ?
A shopper on Oct 22, 2018
  This amplifier will drive AR90's very well.
How long did it take to receive it after it was ordered ?
A shopper on Dec 5, 2017
  Most McIntosh gear, including this unit, are only available in store and cannot be shipped. This particular unit is brand new, and only went into production in November. We were one of the first companies to place a pre-order for our stock, and we expect them to arrive any day now!
