Kicker

Kicker CXA800.1 800-Watt Class D Mono Amplifier

Regular price $269.96
Sale price $269.96 Regular price
$299.99 Save $30.03 (10%)
OR

Limited time offer! Sale ends 4/28/2024.
In Stock & Ready to Ship
Free Shipping Get it between Tue, Apr 23 – Tue, Apr 30

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: 46CXA8001T | UPC: 713034012818

Specifications

What's In The Box

Product Documents

Product Information

Model: 46CXA8001T | UPC: 713034012818

The CXA800.1 Mono Amplifier is built for affordable power and performance, thanks to optimized circuit layout and high-grade internal components.

About That Power

This CX-Series Mono Amp is now one-ohm stable, giving you even more power and wiring options for your system! Using a Class-D power plant, the CXA800.1 features a variable bass boost with KickEQ™, giving you as much as a 6dB of extra bump with a simple turn of the optional CXARC Remote Bass Controller. A powerful 12dB crossover and 24dB subsonic filter is included, letting you quickly tune your system to perfection. Use the full-range outputs to expand your system with other bass amps, or a full-range amp to complete your system. CX-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time! Expand your system with full-range, RCA pass-through outputs, then choose a “standard” mount or a cool vertical mount with the included hardware. This CX.1 amplifier delivers as much as 800 watts into one bass channel.

Features

  • Efficient Class-D amplifier
  • Three-second turn-on/off delay to eliminate unwanted interference
  • Variable 12dB crossovers provides control to dial in perfect sound
  • KickEQ™ 6dB variable bass boost for those additional low frequencies
  • 24dB subsonic filter for protection from potentially damaging frequencies
  • FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
  • Accepts up to 40-volt input signal
  • Small footprint for easier installation
  • Compatible with CXARC (link to remote) Remote Bass Control
  • Vertical mounting hardware included for another unique look

Specifications

  • Power (watts/ch) 4 Ohm: 300 x 1
  • Power (watts/ch) 2 Ohm: 600 x 1
  • Power (watts/ch) 1 Ohm: 800 x 1 +/-10%
  • CXRC Remote Bass Capable (sold sep.): Yes
  • Dimensions (HxWxL): 2-3/8, 5.9H x 6-3/4, 17W x 8-1/8, 20.6L
  • Frequency Response (Hz): 25-200Hz
  • Input Sensitivity:
    • 250mV-10V (Low Level)
    • 1V-40V (High Level)
  • Signal-to-Noise Ratio: >95dB, a-weighted, re: rated power
  • Active Crossover: Variable Low-pass 50Hz-200Hz, 12dB/octave
  • Subsonic Filter: 25Hz @ 24dB/octave
  • KickEQ™ Boost: Variable 0-6dB @ 40Hz

What's In The Box

  • CXA800.1 800-Watt Class D Mono Amplifier
  • Mounting hardware
  • Owner's manual
