Kicker 46CXA1200.1 1200-Watt Class D Monoblock Subwoofer Amplifier

Model: 46CXA12001T UPC: 713034012757 Item: 172624

Product Information

46CXA1200.1 1200-Watt Class D Monoblock Subwoofer Amplifier

The CXA1200.1 Mono Amplifier is built for affordable power and performance, thanks to an optimized circuit layout and the high-grade internal components.

Mono Monster

This mono CX-Series Amp is now one-ohm stable, giving you even more wiring options for your system! Using a Class-D power plant, the CXA1200.1 features a variable bass boost with KickEQ™, giving you as much as a 6dB of extra bump with a simple turn of the optional CXARC Remote Bass Controller. A powerful 12dB crossover and 24dB subsonic filter is included, letting you quickly tune your system to perfection.

CX-Series Amplifiers accept up to 40 volts (400 watts) of speaker-level input signal. This kind of flexibility both makes line-out converters unnecessary and optimizes your sound quality at the same time!

Use the full-range outputs to expand your system with other bass amps, or add a full-range amp to complete your system.

This CX.1 Amplifier delivers as much as 1,200 watts into one bass channel.

Features:

  • Efficient Class-D amplifier
  • Three-second turn-on/off delay to eliminate unwanted interference
  • Variable 12dB crossovers provides control to dial in perfect sound
  • KickEQ™ 6dB variable bass boost for those additional low frequencies
  • 24dB subsonic filter for protection from potentially damaging frequencies
  • FIT+™ (Fail-safe Integration Technology-PLUS) means it works with nearly every radio
  • Accepts up to 40-volt input signal
  • Small footprint for easier installation
  • Compatible with CXARC Remote Bass Control
  • Vertical mounting hardware included for another unique look

Specifications

Specifications:

  • Power (watts/ch) 4 Ohm: 600 x 1
  • Power (watts/ch) 2 Ohm: 1200 x 1
  • Power (watts/ch) 1 Ohm: 1200 x 1 +/-10%
  • CXRC Remote Bass Capable (sold sep.): Yes
  • Dimensions (HxWxL): 2-3/8, 5.9H x 6-3/4, 17W x 12, 30.6L
  • Frequency Response (Hz): 25-200Hz
  • Input Sensitivity:
    • 250mV-10V (Low Level)
    • 1V-40V (High Level)
  • Signal-to-Noise Ratio: 95dB
  • Active Crossover: Variable Low-pass 50Hz-200Hz, 12dB/octave
  • Subsonic Filter: 25Hz @ 24dB/octave
  • KickEQ™ Boost: Variable 0-6dB @ 40Hz

What's in the Box

What's in the Box:

  • One 46CXA1200.1 amplifier
  • Mounting hardware
  • Owner's manual

Documents

Reviews

Customer Reviews for Kicker 46CXA1200.1 1200-Watt Class D Monoblock Subwoofer Amplifier

There are no reviews for this item. Write Review

Q&A

Customer Q & A

Have a functionality, compatibility, or otherwise product-specific question about this product? Ask it here! If you have a customer service or shipping question, please direct it to our customer service department

Start typing your question and we'll check if it was already asked and answered. Learn More
Browse 1 question Browse 1 question and 1 answer
Why did you choose this?
World Wide Stereo Store
I choose this amp as I needed 1200 watts RMS at 2 ohm stable. I will be pushing a Kicker L7 Q-class 15 with dual 4 ohm voicecoils. I plan to buy another amp and 15 within the next few months. My car is already setup with a 240 amp alternator and big three upgrade.
AFilthy H on Jan 18, 2021
I choose this amp as I needed 1200 watts RMS at 2 ohm stable. I will be pushing a Kicker L7 Q-class 15 with dual 4 ohm voicecoils. I plan to buy another amp and 15 within the next few months. My car is already setup with a 240 amp alternator and big three upgrade.
AFilthy H on Jan 18, 2021
