Kicker 46CSC684 CS-Series 6x8" 2-Way Coaxial Speakers

Regular price $89.99
Sale price $89.99 Regular price
Save $-89.99 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Thu, Dec 12 – Thu, Dec 19

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: 46CSC684 | UPC: 713034088387

Specifications

What's In The Box

Product Information

Model: 46CSC684 | UPC: 713034088387

46CSC684 CS-Series 6x8" 2-Way Coaxial Speakers

The CS Series delivers remarkable performance and ultra-clean bass, utilizing a heavy-duty motor/magnet structure featuring EVC™ (Extended Voice Coil) technology not found in stock speakers. They use polypropylene cones with tough, ribbed, UV-treated surrounds for precise linear excursion and reliability.

CS Series CSC68

CS-Series 6x8-inch Coaxial Speakers are the perfect way to upgrade your factory system.

CS-Series Coaxials deliver remarkable performance and ultra-clean bass with a heavy-duty motor/magnet structure not found in stock speakers. A stamped-steel frame supports a rigid polypropylene cone with EVC™ (Extended Voice Coil) technology for the best sonic quality. Using zero-protrusion PEI tweeters with neodymium magnets, you get the clarity you need without interfering with factory grilles.

These CS speakers work best with 75 watts of recommended power.

  • Fits nearly every car made
  • Zero-protrusion tweeters to fit nearly any factory depth
  • Woofer EVC™ (Extended Voice Coil) tech assists with precise linear excursion
  • UV-treated poly-foam surround resists heat or direct sunlight
  • Large woofer magnet in a heavy-duty motor for ultra-clean bass
  • PEI-tweeter construction provides superb clarity
  • Neodymium tweeter magnets allow for increased volume in high frequencies

Specifications

  • Speaker Design: 2-way
  • Woofer Size (in, mm): 6x8, 160 x 200
  • Tweeter Size (in, mm): 1/2, 13
  • DC Resistance: 3.5 ohms
  • Peak Power: 225 watts
  • Continuous Power: 75 watts
  • Sensitivity: 90dB
  • Effective Frequency Range: 45Hz - 20kHz
  • Mounting Hole Diameter (in, mm): 5x7-3/16, 126 x 182
  • Top Mount Depth (in, mm): 3/8, 9
  • Bottom Mount Depth (in, mm): 2-3/16, 56
  • Tweeter Protrusion (in, mm): 0
  • Grilles: No
  • Tweeter Magnet Material: Neodymium
  • Tweeter Dome Material: PEI (polyether imide)
  • Tweeter Design: Balanced dome
  • Woofer Cone Material: Polypropylene
  • Woofer Surround Material: Polyester foam

What's In The Box

  • One pair of 46CSC684 speakers
  • Owner's manual
