Kenwood XM802-5 Class D 5-Channel Marine Power Amplifier

$450.00 OR

Regular Price: $550.00

Save: $100.00 (18%)

Out of Stock

More Product Details

Our product experts are here to help

Questions? We're here to help.

Model: XM802-5 UPC: 019048233851 Item: 177638

Product Information

Ready to outfit your Side-by-Side, Watercraft, Off-Read Vehicle, and more? The Kenwood eXcelon Motorsports XM802-5 is a Class-D 5-Channel Marine-Grade Power Amplifier. The inclusion of a conformal coated circuit board, a protective terminal cover, and stainless-steel mounting screws ensure this amplifier is ready for the elements.

Complete Separation

  • Each block is completely separated - Analog Circuit, Digital Amplifier, Power Supply
  • Pattern layers of PCB do not overlap

Conformal Coating

  • Prevents corrosion
  • Stabilizes circuit board patterns

Protective Terminal Cover

  • Plastic screw-in cover to restrict dust and moisture entry

Installation Flexibility

  • Variable Controls: For crossovers, gain, and bass boost
  • All Connections on 1 Side: Easier installation & a cleaner look
  • Optional Remote Sub Level Controller: KCA-RC01A Ready
  • Included Speaker Level Input Harness




  • 50W x 4 + 300W x 1 @ 4 ohms (RMS)
  • 75W x 4 + 500W x 1 @ 2 ohms (RMS)
  • 150W x 2 Bridged @ 4 ohms + 500W x 1 @ 2 ohms (RMS)
  • Conformal Coated Circuit Board
  • Protective Terminal Cover
  • Stainless-Steel Mounting Screws
  • Signal Sensing Turn-On
  • Power MOS-FET Switching Power Supply
  • Speaker Level Input w/ included cable
  • Bass Boost 40Hz, 0-18dB - Sub
  • LP Crossover 50-200Hz 24dB - Sub
  • HP Crossover 50-200Hz 12dB - A&B
  • Wired Remote Level Control Ready (KCA-RC01A sold separately)
  • Dimensions: 9-3/4" x 2-1/16" x 6-5/8"
  • 2 year warranty
