Kenwood

Kenwood DPX395MBT eXcelon Digital Media Receiver with Bluetooth and Amazon Alexa Built-In

Regular price $139.00
Sale price $139.00 Regular price
Save $-139.00 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Thu, Nov 30 – Thu, Dec 7

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Kenwood DPX395MBT eXcelon Digital Media Receiver with Bluetooth and Amazon Alexa Built-In Overview

Product Information

Model: DPX395MBT | UPC: 019048233677

Specifications

What's In The Box

Product Information

Model: DPX395MBT | UPC: 019048233677

Features

  • 420 Segment 3 Line Text Display
  • Amazon Alexa Ready
  • Bluetooth Direct Access Button
  • Short Chassis
  • 13Band EQ & Digital Time Alignment
  • Variable Color Illumination
  • 200mm Escutcheon Panel Included (for fit in latest model Japanese and other select cars)
  • 3 Preouts 5.0V

Music Mix

Up to 5 Bluetooth® devices can be paired to the receiver at the same time. You can enjoy audio streaming just by switching the devices with your friends or family.

Dual Phone Connection

While you are connected through Bluetooth, with a touch of a button you can switch between two phones.

Remote App

A smartphone application can control most basic functions of the receiver over the Bluetooth connection of the paired phone (iPhone or Android).

Graphic EQ / Digital Time Alignment

13-Band equalizer and DTA gives optimal tuning enhancements for listeners.

Drive EQ

Boosts specific frequencies in the audio signal to overcome the negative impact of road noise.

Variable Color Illumination

Bright variable color LEDs can be adjusted to match any color dash lighting.

Short Chassis

With receivers shorter in depth than any of our previous models, installation is made easier in a wider range of cars.

200mm ESCUTCHEON Included

A 200mm escutcheon is included to help make the fit seamless in many of the latest model Japanese and other select cars.

Specifications

  • FM
    • Frequency Range(MHz): 87.9MHz to 107.9MHz (Frequency step 200kHz)
    • Usable Sensitivity (S/N:30dB): 8.2dBf (0.71μV/75Ω)
    • Quieting Sensitivity (DIN S/N:46dB): 17.2dBf (2.0μV/75Ω)
    • Frequency Response (±3.0dB): 30Hz to 15kHz
    • S/N(dB): 64.0dB (MONO)
    • Stereo Separation: 40dB (1kHz)
  • MW (AM)
    • Frequency Range(kHz): 530kHz to 1700kHz (Frequency step 10kHz)
    • Usable Sensitivity (S/N 20dB): 29dBμ (28.2μV)
    • Preout Level(mV)/Load -Unbalanced: 5,000mV/10kΩ
    • Preout Impedance(Ω): =<600Ω
    • Speaker Impedance(Ω): 4 to 8Ω
  • USB I/F
    • USB: USB 1.1 / 2.0 High Speed
    • File System: FAT12 / 16 / 32
    • Maximum Supply current: DC5V (DC logo) 1.5A
    • Frequency Response: 20Hz to 20kHz (±1dB)
    • S/N Ratio (dB): 98dB(1kHz)
    • Dynamic Range: 93dB
    • Channel Separation: 90dB
    • MP3 Decode: Compliant with MPEG-1/2 Audio Layer-3
    • WMA Decode: Compliant with Windows Media Audio
    • AAC Decode: AAC-LC ".aac",".m4a" files
    • WAV Decode: Linear-PCM
    • FLAC Decode: FLAC file (Up to 24bit/96kHz)
  • AUX Input
    • Frequency Response: 20Hz to 20kHz ±3dB
    • Input Maximum Voltage: 1,000mV
    • Input Impedance: 30kΩ
  • AMP
    • Maximum Power: 50Wx4
    • Full Bandwidth Power (at less than 1%THD): 22Wx4
  • Tone
    • Band1: 62.5Hz ±9dB
    • Band2: 100Hz ±9dB
    • Band3: 160Hz ±9dB
    • Band4: 250Hz ±9dB
    • Band5: 400Hz ±9dB
    • Band6: 630Hz ±9dB
    • Band7: 1kHz ±9dB
    • Band8: 1.6kHz ±9dB
    • Band9: 2.5kHz ±9dB
    • Band10: 4kHz ±9dB
    • Band11: 6.3kHz ±9dB
    • Band12: 10kHz ±9dB
    • Band13: 16kHz ±9dB
  • Bluetooth
    • Version: Bluetooth 4.2
    • Frequency Range: 2.402 to 2.480GHz
    • RF Output Power (E.I.R.P.): +4dBm (MAX), Power Class 2
    • Maximum Communication range: Line of sight approx.10m (32.8ft)
    • Profile
      • HFP 1.7.1 (Hands Free Profile)
      • SPP (Serial Port Profile)
      • PBAP (Phonebook Access Profile)
      • A2DP (Advanced Audio Distribution Profile)
      • AVRCP 1.6.1 (Audio/Video Remote Control Profile)
  • General
    • Operating voltage: 12V DC car battery
    • Installation Size (W x H x D): 7-3/16” x 4-3/8” x 3-15/16”
    • Net Weight: 2.2 lbs

What's In The Box

  • DPX395MBT Excelon Digital Media Receiver with Bluetooth and Amazon Alexa Built-In
  • Wiring Harness
  • (6) Flat Head Screws
  • (6) Round Head Screws
  • Microphone with bracket (3.5mm connector)
  • Trim rings
  • (2) Extraction Keys
  • Quick Start Guide
  • Warranty
