Specifications
Specifications
- Picture size: 6.75 inches(diagonal) wide
- W x H: 152.1 mm x 79.5 mm, 5-63/64 x 3-1/8 inch
- Display system: AAS LCD panel
- Drive system: TFT active matrix system
- Number of pixels: 2,764,800 1280H x 720V x RGB
- Effective pixels: 99.99%
- Pixel arrangement: RGB striped arrangement
- Back lighting: LED
- DVD Section: D/A Converter 24 / 32Bit
- Audio Decoder: Linear PCM
- Dolby Audio
- MP3 / WMA / AAC / WAV / FLAC / Vorbis
- Video Decoder: MPEG1/2,MPEG4 / WMV / H.264 / MKV
- Wow & Flutter: Below Measurable Limit
- Frequency response 96k Sampling: 20 - 44,000 Hz
- 48k Sampling: 20 - 22,000 Hz
- 44.1k Sampling: 20 - 20,000 Hz
- Total harmonic distortion 1kHz: 0.010%
- Signal to Noise ratio: 90.5dB (DVD-Video 96k)
- Dynamic range: 89dB (DVD-Video 96k)
- DISC Format: DVD-Video / VIDEO-CD / CD-DA
- Quantifying bit number: 16 / 20 / 24bit
- USB I/F Section: USB Standard USB2.0 High Speed
- File System: FAT 16/32, exFAT, NTFS
- Maximum Power Supply Current: DC5V=1.5A
- D/A Converter: 24/32Bit
- Audio Decoder: MP3 / WMA / AAC / WAV / FLAC / Vorbis
- Video Decoder: MPEG1/2,MPEG4 / WMV / H.264 / MKV
- Wireless Mirroring Section: Mode, Sink
- Copyright protection: HDCP2.2
- Touch Control: UIBC
- Wi-Fi: IEEE Standard 802.11 a/b/g/n/ac
- Frequency Range: Dual Band ( 2.4GHz / 5GHz )
- Channels: Auto(1-11ch)
- Auto (149,153,157,161ch)
- Transfer rates (MAX):
- 11a: 54 Mbps / 11b: 11 Mbps /
- 11g: 54 Mbps / 11n: 300 Mbps /
- 11ac: 867 Mbps
- Output Power 2.4GHz/SISO: 11b:14dBm±2dB / 11g:13dBm±2dB / 11n(20MHz):12dBm±2dB
- Output Power 5GHz/SISO: 11a:9dBm±2dB / 11n(20MHz):9dBm±2dB / 11n(40MHz):8dBm±2dB / 11ac(20MHz):9dBm±2dB / 11ac(40MHz):8dBm±2dB / 11ac(80MHz):8dBm±2dB
- Output Power 5GHz/MIMO: 11n(20MHz):11dBm±2dB / 11n(40MHz):11dBm±2dB / 11ac(20MHz):11dBm±2dB / 11ac(40MHz):11dBm±2dB / 11ac(80MHz):11dBm±2dB
- Bluetooth Section:
- Technology: Bluetooth Ver5.0
- Frequency: 2.402 – 2.480 GHz
- RF Output Power (E.I.R.P.): +4dBm (MAX), Power Class 2
- Maximum Communication range: Line of sight approx.10m(32.8ft)
- Audio Codec: SBC / AAC / LDAC
- Multi Profile Support: Multi Profile
- Profile:
- HFP (V1.7) (Hands Free Profile)
- SPP (Serial Port Profile)
- A2DP (Advanced Audio Distribution Profile)
- AVRCP (V1.6) (Audio/Video Remote Control Profile)
- PBAP (Phonebook Access Profile)
- DSP Section: Graphics equalizer
- Color system of external video input: NTSC/PAL
- External video input level (Mini jacks): 1 Vp-p / 75 Ohms
- External audio max input level (Mini jacks): 2 V / 25 kOhms
- Video Input level (RCA jacks): 1 Vp-p / 75 Ohms
- Video Output level (RCA jacks): 1 Vp-p / 75 Ohms
- Audio Output level (Mini jacks): 0.9 V / 10 kOhms
- Maximum Power Output (Front&Rear): 50Wx4
- Typical Power Output (Front&Rear): Full Bandwidth Power (at less than 1%THD) 22Wx4
- Output frequency band: 20 - 88,000Hz
- Preout level (V): 5V / 10kOhms
- Preout impedance (Ω): =< 300 Ohms
- Speaker Impedance (Ω): 4-8 Ohms
- Navigation Section:
- Operating voltage: 12V DC Car Battery
- Installation Dimensions WxHxD: 178mm x 100mm x 160mm (7 x 3-15/16 x 6-5/16 inch)
- (with Sleeve): 182mm x 112mm x 163mm (7-3/16 x 4-7/16 x 6-7/16 inch)
- Weight Main unit: 2.4 kg (5.3 lb)
- (Excluding trim plate and sleeve)
What's in the Box
What's in the Box
- DVD Receiver
- Sleeve
