KASA500 is a powerful Class-D Dual 250WPC amplifier. This DSP controlled system amplifier is optimized to deliver thunderous bass from KEF Ci subwoofers. With both line and speaker level inputs, and DSP configurable pass-through with optional high pass filters – the KASA500 is versatile and can be deployed in limitless system configurations.
Overview
Product Information
Specifications
What's In The Box
Product Information
Specifications
- Crossover Frequencies: 40 - 140Hz or software bypass
- Inputs: Selectable stereo RCA line level, or mono LFE RCA level; Stereo speaker level
- 12 Volt Trigger Input Voltage: 8 to 14 Volt DC @ 1.5mA max, 1/8" diameter female plug (tip positive or tip negative)
- Amplifier Power
- 2 x 250 watts @ 4 ohms
- Bridge: 1 x 500 watts @ 8 ohms (<1% THD)
- Product External Dimension (H x W x D): 3.5 x 17 x 12 in.
- With feet: 3.62 x 17 x 12 in.
- With rack ears; 2 EIA rack space: 3.5 x 19 x 12 in.
- Weight: 9 lbs.
What's In The Box
- KASA500 Subwoofer Amplifier with Rack Ears
- Rack Installation Hardware
- Power Cord
- Manual
