JL Audio JD500/1 Class D Monoblock Amplifier - 500 Watts @ 2 Ohms

Model: JD500/1 UPC: 699440983624 Item: 174933

Product Information

Overview

Monoblock Class D Subwoofer Amplifier, 500 W x 1 @ 2 Ω / 250 W x 1 @ 4 Ω - 14.4V

Designed to produce a whopping 500 watts into 2 ohms (14.4V, 1% THD), the JD500/1 amplifier is a great solution for powering subwoofers in a cost-conscious system. JL Audio's proprietary NexD™ switching technology delivers large amounts of real-world power output with excellent efficiency and ultra-low distortion.

The JD500/1’s controls are located on the input panel. while the power and speaker connections can be found along the opposite end of its extruded aluminum chassis. Signal processing features include a 12 dB / octave low-pass filter, with continuously variable frequency selection from 50-500 Hz, and a variable bass boost EQ. Dual-range, differential-balanced inputs are also on-hand, capable of accepting line-level and speaker-level signals. Automatic turn-on capability (via signal sensing or DC-offset sensing) is standard, along with a set of preamp outputs so you can easily pass signals to another amplifier.

The JD500/1 is also equipped with an onboard LED-clipping indicator ring, surrounding the input sensitivity control. This useful feature lets you set your amplifier’s input sensitivity, quickly and accurately, without special equipment. With the addition of an RBC-1 remote level control (sold separately), you can control the subwoofer level from the driver’s seat.

Specifications

Specifications

  • Rated Continuous (RMS) Power @ 14.4V
    • @ 4 Ohms: 250 watts x 1
    • @ 3 Ohms: 350 watts x 1
    • @ 2 Ohms: 500 watts x 1
    • @ 1.5 Ohms: N/A
  • Rated Continuous (RMS) Power @ 12.5V
    • @ 4 Ohms: 225 watts x 1
    • @ 3 Ohms: 300 watts x 1
    • @ 2 Ohms: 400 watts x 1
    • @ 1.5 Ohms: N/A
  • General Specifications
    • Frequency Response: 7 Hz - 500 Hz (+0, -1dB)
    • S/N Ratio, referred to highest rated power: >80 dB below rated power (A-weighted, 20 Hz - 20 kHz noise bandwidth)
    • S/N Ratio, referred to 1 W: >60 dB (A-weighted, 20 Hz - 20 kHz noise bandwidth)
    • Damping Factor @ 4 ohms: >1000 / 50 Hz
    • Damping Factor @ 2 ohms: >500 / 50 Hz
    • THD+N @ Rated Power: <1% @ 2 ohms per Ch.
    • Input Voltage Range @ RCA Inputs: Switchable from 200 mV - 2 V RMS (Low) to 800 mV - 8 V RMS (High)
    • Min.Copper Power / Ground Wire Gauge: 4 AWG wire
    • Fuse Rating: 50 A (AFS, AGU or MaxiFuse)
  • Signal Processing
    • Filter Mode(s): Low-Pass only
    • Filter Slope(s): 12 dB/octave
    • Filter Frequency Range: 50 Hz - 500 Hz
    • Detented, Calibrated Filter Freq. Potentiometer: No
    • Filter Defeat Function: No
    • Infrasonic Filter: No
    • Bass Boost EQ: Yes
    • Output Polarity Switch: No
    • Remote Subwoofer Level Control: Optional (RBC-1)
    • Remote Bass EQ Boost Control: No
    • Pass-Through Preamp Output: Buffered
  • Physical Specifications
    • Height (H): 2.10 in / 53 mm
    • Width (W): 9.50 in / 242 mm
    • Depth (D): 7.50 in / 190 mm

What's in the Box

What's in the Box

  • JD500/1 amplifier
  • 2.5mm hex wrench
  • 3mm hex wrench
  • Owner's manual
