Bowers & Wilkins HTM71 S3 Signature 3-Way Center Channel Speaker (Datuk Gloss)
Bowers & Wilkins HTM71 S3 Signature Center Channel Speaker Overview
Product Information
Specifications
What's In The Box
Product Information
Crafted. Honed. Perfected.
The HTM71 S3 Signature arrives as a first-of-its-kind Signature center channel speaker. Designed predominantly for use in home theatres, the HTM71 S3 Signature delivers exceptional vocal realism to any movie-watching experience. It features optimized technologies, such as Bowers & Wilkins’ proprietary decoupled Continuum midrange drive unit and Tweeter-on-Top, plus upgraded bass motor systems, improved capacitors, revised speaker terminals, and a more open tweeter grille mesh, as developed for their 800 Series Signature loudspeakers.
Solid Body Tweeter
The 700 Series Signature models feature the latest generation of Bowers & Wilkins’ iconic Solid Body Tweeter-on-Top housing. Its new, more elongated form incorporates a longer tube-loading system to produce an even more free and open sound with high frequencies. The carefully decoupled housing is milled from a single solid block of aluminum to better resist resonance.
Carbon Dome Tweeter
Carbon Dome tweeters are purpose-built for the 700 Series. Delivering a dramatic improvement on older generations of tweeter dome technologies, they raise the breakup threshold to 47kHz, for pinpoint imaging accuracy and detail.
Biomimetic Suspension
Sometimes, making a big difference takes unconventional thinking. The transition from Bowers & Wilkins’ famous yellow Aramid Fiber midrange cones to their Continuum cone technology resulted in a massive improvement to midrange performance. Now, they’ve turned their attention to another crucial element in a loudspeaker cone: the fabric spider. The new Biomimetic Suspension revolutionizes midrange cone performance by greatly reducing the unwanted air pressure and coloration that a conventional fabric spider can generate. The result? Midrange transparency you wouldn’t believe possible.
Continuum™ Cone
Thanks to its composite construction, the Continuum™ cone avoids the abrupt transitions in behavior that can impair the performance of a conventional drive unit. The result is a more open, neutral performance that delivers voices and instruments with precision and transparency.
Upgraded Crossovers
The new 700 Series Signature models use upgraded crossover designs crafted by Bowers & Wilkins’ expert engineers. Developed using rigorous testing, their engineers carefully optimize these crossovers to perfection, to maximize the loudspeakers’ performance.
Aerofoil™ Profile Bass Cone
Developed using advanced computer modelling techniques, the Aerofoil™ Profile bass cone has variable thickness, providing stiffness and rigidity where it’s needed most. The result is deep and dynamic bass.
Curved Baffle
The new 700 Series Signature models feature a curved front baffle. This allows the midrange and bass drivers to be located in individual pod-type housings that sit proud of the speaker baffle. When combined with the curvature of the structure, this new approach – derived from the 800 Series Diamond – reduces the audible impact of the cabinet, creating a cleaner, more open and more immersive sound.
Specifications
- Technical Features
- Decoupled Carbon Dome tweeter
- Solid Body Tweeter-on-Top
- Continuum™ cone FST" midrange
- Aerofoil™ Profile bass cones
- Flowport™
- Description: 3-way vented-box system
- Drive Units
- 1x 25mm (1 in) Decoupled Carbon Dome high-frequency
- 1x 130mm (5 in) Continuum cone FST midrange
- 2x 130mm (5 in) Aerofoil Profile Bass
- Frequency Range: -6dB 45Hz - 33kHz
- Frequency Response (+/-3dB from reference axis): 50Hz - 28kHz +3dB
- Sensitivity (on axis at 2.83Vrms at 1m): 89dB
- Harmonic Distortion
- 2nd and 3rd harmonics (90dB, 1m on axis)
- <1% 90Hz - 22kHz
- <0.5% 120Hz - 20kHz
- Nominal Impedance: 8Ω (minimum 3Ω)
- Recommended Amplifier Power: 30W - 200W into 8Ω on unclipped program
- Max. Recommended Cable Impedance: 0.1Ω
- Dimensions
- Cabinet Only (W x H x D): 24.7” x 6.5” x 12.5”
- Including Grille and Terminals (W x H x D): 24.7” x 9.2” x 14”
- Net Weight: 43.9 Ibs
What's In The Box
- HTM71 S3 Signature 3-Way Center Channel Speaker - Each
