Audio-Technica AT-VM740xML/H VMx Headshell & Microlinear Dual MM Cartridge Combo Kit

Regular price $309.00
Sale price $309.00 Regular price
Save $-309.00 (%)
OR

In Stock & Ready to Ship
Free Shipping Get it between Tue, Jun 24 – Tue, Jul 1

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: AT-VM740XML/H | UPC: 4961310163310

Specifications

What's In The Box

Product Information

Model: AT-VM740XML/H | UPC: 4961310163310

The AT-VM740xML/H combo kit includes the AT-VM740xML microlinear dual moving magnet cartridge premounted on the AT-LT10 universal 1/2"-mount headshell. The AT-VM740xML is part of the updated AT-VMx series, which introduces material and design changes to further refine the VM sound, offering responsive playback that is especially sensitive to the dynamism of musical expression.

Features

AT-VM740xML Dual Moving Magnet Cartridge

  • Microlinear Stylus
  • Paratoroidal Coils Improve Channel Separation, Channel Balance, and Transient Response
  • Center Shield Plate Reduces Crosstalk
  • Durable Low-Resonance Polymer Housing
  • Aluminum Cantilever
  • Compatible with Any Turntable Headshell That Accepts 1/2” Cartridges

AT-LT10 Universal ½”-Mount Headshell

  • For 4-Pin Turntable Cartridges with or Without Threaded Inserts
  • Ultra-Lightweight Aluminum Die-Cast Body Keeps Vibration to the Bare Minimum
  • Elongated Through Holes Enable Precise Cartridge Positioning and Overhang Adjustment
  • OFC (Oxygen-Free Copper) Lead Wires for Exceptional Sound Quality
  • Slip-Resistant Finger Lift Allows Stylus to Be Placed Precisely on the Record
  • Includes Mounting Screws

Specifications

  • Type: VM
  • Frequency response: 20 to 25,000 Hz
  • Output voltage: 3.2 mV (1 kHz, 5 cm/sec.)
  • Channel separation: 25 dB (1 kHz)
  • Output balance: 1.0 dB (1 kHz)
  • Tracking force: 1.8 to 2.2 g (2.0 g standard)
  • Coil impedance: 3.2 k ohms (1 kHz)
  • DC resistance: 750 ohms
  • Recommended load impedance: 47 k ohms
  • Recommended load capacitance: 150 to 250 pF
  • Coil inductance: 480 mH (1 kHz)
  • Static compliance: 20 × 10?6 cm/dyne
  • Dynamic compliance: 7 × 10?6 cm/dyne (100 Hz)
  • Stylus: Nude Microlinear
  • Stylus curvature radius: 2.2 × 0.12 mil
  • Cantilever: Aluminum tapered pipe
  • Vertical tracking angle: 20°
  • Dimensions: 2.7” × 0.73” × 0.85”
  • Weight: 20.3 g (0.72 oz)
  • Replacement stylus (sold separately): AT-VMN40xML

What's In The Box

  • AT-VM740xML/H VMx Headshell & Microlinear Dual MM Cartridge Combo Kit
  • Installation Hardware
  • Manual
