Specifications
Specifications
- Monitor Section
- Picture size: 6.2" (diagonal) wide
- W x H: 6-3/16" x 3-3/16"
- Display system: Transparent TN LCD panel
- Drive system: TFT active matrix system
- Number of pixels: 800H x 480V x RGB
- Effective pixels: 99.99%
- Pixel arrangement: RGB striped arrangement
- Backlighting: LED
- DVD Section
- D/A Converter: 24Bit
- Audio Decoder: Linear PCM, Dolby Audio, MP3 / WMA / AAC(.m4a) / WAV
- Video Decoder: MPEG1 / MPEG2
- Wow & Flutter: Below Measurable Limit
- Frequency response
- 96k Sampling: 20 - 20,000 Hz
- 48k Sampling: 20 - 20,000 Hz
- 44.1k Sampling: 20 - 20,000 Hz
- Total harmonic distortion 1kHz: 0.010%
- Signal to Noise ratio: 82dB (DVD-Video 96k)
- Dynamic range: 81dB (DVD-Video 96k)
- DISC Format: DVD-Video / VIDEO-CD / CD-DA
- Sampling frequency: 44.1kHz / 48kHz / 96kHz
- Quantifying bit number: 16 / 20 / 24bit
- USB I/F Section
- USB Standard: USB2.0 Full Speed / High Speed
- Compatible Devices: Mass storage class
- File System: FAT 16/32, NTFS
- Maximum Power Supply Current: DC5V (DC logo) = 1.5A
- D/A Converter: 24bit
- Audio Decoder: MP3 / WMA / AAC(.m4a) / WAV / FLAC
- Video Decoder: MPEG1/2,MPEG4 / WMV / H.264 / MKV
- Frequency response
- 192k Sampling -
- 96k Sampling -
- 48k Sampling -
- 44.1k Sampling -
- Total harmonic distortion 1kHz -
- Dynamic range -
- Bluetooth Section
- Technology: Bluetooth Ver3.0
- Frequency: 2.402 – 2.480 GHz
- Output Power: +4dBm (MAX),0dBm (AVE) Power Class 2
- Maximum Communication range: Line of sight approx.10m(32.8ft)
- Audio Codec: SBC / AAC
- Profile
- HFP(Hands Free Profile) 1.6
- A2DP(Advanced Audio Distribution Profile) 1.3
- AVRCP(Audio/Video Remote Control Profile) 1.5
- GAP(Generic Access Profile)
- PBAP(Phonebook Access Profile) 1.2
- SDP(Service Discovery Profile)
- SPP(Serial Port Profile) 1.2
- FM
- Frequency Range: 87.9MHz - 107.9MHz
- (Frequency step): (200kHz)
- Usable sensitivity: 7.2 dBf
- S/N:30dB Dev. 22.5kHz: 0.63 μV / 75 Ohms
- Quieting sensitivity: 15.2 dBf
- DIN S/N:46dB Dev.40kHz: 1.58 μV / 75 Ohms
- Frequency response: 30Hz - 15kHz
- S/N (dB): 68dB (MONO)
- Selectivity: Over 80dB (±400kHz)
- Stereo separation: 40dB (1kHz)
- AM
- Frequency Range: 530kHz - 1700kHz
- (Frequency step): (10kHz)
- Usable sensitivity: 29 dBμ
- Digital FM
- Frequency Range: 87.9MHz - 107.9MHz
- (Frequency step): (200kHz)
- Frequency Response: 20Hz - 20kHz
- S/N: 75dB (STEREO)
- Digital AM
- Frequency Range: 530kHz - 1700kHz
- (Frequency step): (10kHz)
- Frequency Response: 40Hz - 15kHz
- S/N : 75dB (STEREO)
- DAB
- Frequency Range: -
- Sensitivity: -
- S/N: -
- DAB Antenna Connector
- Connector type: -
- Output Voltage(11V-16V): -
- Maximum Current: -
- Video
- Color system of external video input: NTSC / PAL
- External video input level (RCA jack): N/A
- External video input level (mini jack): N/A
- External audio max input level (RCA jack): N/A
- External audio max input level (mini jack): N/A
- Video Input level for Rear Camera (RCA jack): 1 Vp-p / 75 Ohms
- Video Input level for Front Camera (RCA jack): 1 Vp-p / 75 Ohms
- Video Output level (RCA jacks): 1 Vp-p / 75 Ohms
- Audio Output level (mini jacks): N/A
- Analog RGB input: N/A
- Audio
- Maximum Power Output (Front&Rear): 50Wx4
- Typical Power Output (Front&Rear): 22Wx4 (at less than 1%THD)
- Preout level (V): 4V / 10kOhms
- Preout impedance (Ω): =< 600Ohms
- Speaker Impedance (Ω): 4-8 Ohms
- Subwoofer Level: -50 to +10dB
- Equalizer
- BAND: 13Band
- Frequency(Hz): 62.5 / 100 / 160 / 250 / 400 / 630 / 1k / 1.6k / 2.5k / 4k / 6.3k / 10k / 16k
- Gain: -9 / -8 / -7 / -6 / -5 / -4 / -3 / -2 / -1 / 0 / 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 / 9 [dB]
- Q factor: N/A
- 2WAY X'OVER
- Tweeter
- Frequency(Hz): N/A
- Gain: -8/-7/-6/-5/-4/-3/-2/-1/0 [dB]
- Front (HPF)
- Frequency(Hz): Through / 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 / 120 / 150 / 180 / 220 / 250
- Slope: -6 / -12 / -18 / -24 [dB/Oct.]
- Gain: -8 / -7 / -6 / -5 / -4 / -3 / -2 / -1 / 0 [dB]
- Rear (HPF)
- Frequency(Hz): Through / 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 / 120 / 150 / 180 / 220 / 250
- Slope: -6 / -12 / -18 / -24 [dB/Oct.]
- Gain: -8 / -7 / -6 / -5 / -4 / -3 / -2 / -1 / 0 [dB]
- SW (LPF)
- Frequency(Hz): 30 / 40 / 50 / 60 / 70 / 80 / 90 / 100 / 120 / 150 / 180 / 220 / 250 / Through
- Slope: -6 / -12 / -18 / -24 [dB/Oct.]
- Phase: Phase Inversion: Off / On
- Gain: -8 / -7 / -6 / -5 / -4 / -3 / -2 / -1 / 0 [dB]
- Tweeter
- 3WAY X'OVER
- Tweeter (HPF)
- Frequency(Hz): N/A
- Slope: N/A
- Phase: N/A
- Gain: N/A
- Mid Range (HPF)
- Frequency(Hz): N/A
- Slope: N/A
- Mid Range (LPF)
- Frequency(Hz): N/A
- Slope: N/A
- Phase: N/A
- Gain: N/A
- SW (LPF)
- Frequency(Hz): N/A
- Slope: N/A
- Phase: N/A
- Gain: N/A
- Tweeter (HPF)
- Position
- 2Way: Front / Rear /Subwoofer Delay: 0 - 20.01ft (0.03ft Step)
- 3Way: Tweeter / Mid Range / SW Delay: N/A
- Gain: -8 to 0dB
- General
- Operating voltage: 14.4V (10.5V to 16V)
- Maximum Current consumption: 10A
- Installation Dimensions (W x H x D): 7" x 3-15/16" x 6-3/8"
- Operational temperature range: -10°C to +60°C
- Weight
- Main unit: 5.3 lb
