Specifications
Specifications
- Audio
- 11 Channel Amplifier
- 150 Watts per channel (8 ohms, 20 Hz–2- kHz, 0.08% THD, 2-ch driven, FTC)
- All new Integra symmetric class A/B amplifer design
- All new Integra engineered chassis and audio signal path for optimum noise reduction and signal clarity
- Two precision 32-bit ESS ES9026PRO Hyperstream® audiophile DACs
- Control and Service
- Advanced Web App for setup, backup and recall of all avr settings; Default password can be changed by dealer
- Wireless room calibration using Dirac PC/Mac app and optional USB mic (UMIK-1 recommended)
- Quad core network processor for ultimate IP responsiveness and stability
- Assignable amps for Zone 2, Zone 3, and passive subwoofers
- Compatible with OVRC Pro, Domotz, Luxul Pro Watch, VPN, and other monitoring platforms
- Onboard diagnostics tool kit, including test patterns and EDID/HDCP adjustment, virtual remote; all available via web app
- Integra’s most robust API ever, with discrete commands for virtually any AVR function
- Custom control drivers based on Integrator feedback. Developed and maintained by Integra’s software team in Osaka, Japan
- Dirac Live Room Correction
- Dirac Live Premium License INCLUDED (20Hz – 20kHz) – no upgrade required; enables quick out of box setup
- Setup via Dirac PC/MAC app & optional USB mic (Advanced), OR free Integra mobile app & included wired mic (Basic)
- Dirac Live Bass Control ready (single or multi) as an optional user upgrade
- DSP
- 11.4 channel processing for up to 7.2.4 configurations
- 2 INDEPENDENT subwoofer channels plus 2 parallel outputs for connectivity convenience
- Dolby Atmos®, DTS:X®, Auro-3D FW update June ‘23, IMAX Enhanced, Dolby Atmos Music and other major formats
- Network
- Roon Ready (RAAT network interface code preinstalled in the device) (FW update June)
- Chromecast built-in, Airplay 2 (defeatable in AVR setup for smoother client UX)
- Spotify, Amazon Music HD, Tidal, Deezer, Pandora, TuneIn
- Works with Sonos Certified
- AptX HD Bluetooth transmitter for personal listening
- Premium Connections
- 11.4 channel RCA preouts
- XLR preouts for L/C/R/SW1/SW2
- Stereo XLR input
- Video
- Newly designed HDMI 2.1 signal paths with (6) 40Gbps inputs capable of 8K/60 and 4K/120
- Total of 7 HDMI Inputs/3 Outputs & eARC
- Dimensions (W x H x D): 17 1/8” x 7 13/16” x 18 1/2”
- Weight: 49.6 lbs
- Rack Kit (optional): IRK-180-4C
What's in the Box
What’s in the Box
- DRX-8.4 11.4 Channel Network Home Theater A/V Receiver with Dolby Atmos, Dirac Live Room Correction, Roon Ready, Works with Sonos, & Built-In ESS Sabre DAC
- Remote Control (RC-989R)
- Speaker Setup Microphone
- Indoor FM Antenna
- AM Loop Antenna
- Power Cord
- Initial Setup Guide
Reviews
Customer Reviews for Integra DRX-8.4 11.4 Channel Network Home Theater A/V Receiver with Dolby Atmos, Dirac Live Room Correction, Roon Ready, Works with Sonos, & Built-In ESS Sabre DAC
The system this runs is a 7.2.4 with Elac Debut 2.0 fronts, center, and rears, with Elac Debut On-Walls on the sides and ceilings, and 2x SVS SB-2000 Pros. With these speakers, decent room treatment, and the Sony, everything sounded amazing, but the Sony only had one subwoofer signal. I had planned to equalize the subs directly with the SVS App and REW, however that wouldn't work ideally because Sony already "optimizes" the sub-signal, plus it's a science project. So I went with the Integra with 2 independent sub channels (ideal for my room that only has two subs), plus full Dirac and optional Dirac Bass Control. Having recently seen the difference tuning a NAD M23 ($6K stereo) with only Dirac limited, I thought this would be perfect. I was correct.
Setup and tuning was very straightforward, including with the Integra App and mic, although I did redo it with the MiniDSP UMIK-1 and a Mac due to that being Dirac's recommendation. I am now a full Dirac believer, as the tune, especially the bass, is simply incredible. I no longer need to have the SVS App open to lower and increase the volume like I did with the Sony. The response is simply even and works incredibly on movies and music, from classical to electronic. This complete system with the Integra simply eliminates the longstanding problem with bass-- it's always too loud or not loud enough-- on lesser systems. The bass also melts into the speakers just like they say.
In addition to a great remote and UI, I really appreciate that the Integra interprets and tells me on the display the signal it's receiving, so I know I'm actually hearing Atmos (the Sony gave me no such hints). This allowed me to discover that the Apple TV does not reliably send an Atmos signal when Airplaying to it from my phone, but does when playing music directly from the Apple TV app. It also showed me that when I play simultaneously to my Integra and two homepods in an adjacent room (great for parties), it's not playing Atmos, both for movies and music encoded in Atmos. This is not the Integra's fault, and I'm glad it tells me what it's receiving. I am hopeful it can upmix with Auro 3D in this scenario with the upcoming firmware.
One serious improvement to this Integra for some would be more than 2 independent sub-outs, but in my room this is irrelevant with just room for two subs, and the bass is nothing short of astounding with Dirac Bass Control. I'm sure I could improve the sound further with far more expensive speakers, and the Integra could easily drive them, but with a well-treated room, 11 matching Elac Debut 2.0s, powerful subs tuned independently, and full Dirac, any further improvements would just cost money. And in the truest test, I highly doubt my wife could tell the difference, so any improvements I hear would likely be marginal or justified in my head by what I spent.
A little more about the room... it's designed as an Art (Samsung Frame TV) and Music room, that obviously doubles for movies and video games. I'm glad I have the option for XLR inputs for instruments (which the otherwise equivalent Pioneer does not).
I look forward to "improving" this room's sound some day when I upgrade the Elac's and get the next iteration of this Integra, which will surely have Dirac's new Active Room Treatment (ART) that uses the surround speakers themselves to counteract and noise-cancel frequency response issues. Until then, bliss.



- Was this review helpful? Yes (2) No (0)
- Flag as Inappropriate
- Was this review helpful? Yes (2) No (0)
- Flag as Inappropriate
One of the standout features of the Integra DRX 8.4 is the inclusion of Dirac, a highly regarded room correction technology. Also, DRX 8.4 offers the convenience of a web interface, allowing you to access and customize various settings remotely.
In direct comparison to the Marantz Cinema 40 (which I owned before) the Integra DRX 8.4 shines when it comes to sound quality. With its superior amplification, advanced audio processing, and meticulous attention to detail, the DRX 8.4 offers a more refined and engaging audio
In summary, the Integra DRX 8.4 is an outstanding AV receiver that checks all the boxes for audiophiles. Its combination of excellent sound quality, integrated Dirac room correction, convenient web interface, XLR connections, and robust build quality make it a top-tier choice for those seeking a truly high-end audio experience.
- Was this review helpful? Yes (8) No (0)
- Flag as Inappropriate
- Was this review helpful? Yes (8) No (0)
- Flag as Inappropriate
