Specifications
Specifications
- Drive units
- 1x 1" Nautilus tube loaded aluminum dome tweeter
- 1x 6" black glassfibre cone bass/midrange
- Frequency range (-6dB): 45Hz - 35kHz
- Maximum amp power: 25 - 130W
- Sensitivity: 87.5dB (2.83V, 1m)
- Nominal impedance: 8Ω (4.5Ω minimum)
- Frame (H x W): 12.4" x 8.7"
- Cut-out (H x W): 11" x 7.2"
- Depth behind: 3.7"
- Protrusion: 0.2"
What's in the Box
What's in the Box:
- CWM6 Series speaker assembly (baffle, frame, grille)
- Cut-out template
- Paint mask
- Document pack containing Quick Start Guide and Warranty information
