Arcam

Arcam PA240 2-Channel Class G Power Amplifier

Regular price $2,750.00
Sale price $2,750.00 Regular price
Save $-2,750.00 (%)
OR

Need advice?

Consult with a system designer from our showroom.

Call: 1.866.961.7781 Chat Live

Overview

Product Information

Model: ARCPA240AM | UPC: 050667374129

Specifications

What's In The Box

Product Information

Model: ARCPA240AM | UPC: 050667374129

Exceptional Power, Immersive Sound

The PA240 is a high-performance power amplifier that delivers 2 channels of efficient Class G amplification. With an impressive 380W per channel, the PA240 is designed to offer the greatest flexibility and power without compromising on control.

Featuring the best-in-class components including a toroidal based power supply, acoustically damped chassis, paralleled transistor output stages and exceptionally low levels of distortion, the PA240 masters the reproduction of music with all its originality and detail for an unmatched level of sound quality and clarity.

Features

  • 2 Channel Power Amplifier
  • 2 x 380W Class G amplification
  • 1 x 790W Class G bridged mode
  • Class G amplification with 50W of class A operation
  • Toroidal transformer
  • Stereo, Dual Mono or Bridged operation
  • Ethernet, RS232 control
  • Switchable RCA or balanced XLR inputs

Specifications

  • Continuous power output at 0.2% THD per channel
  • 2 channels driven, 4Ω / 8Ω, 20Hz – 20kHz: 380W/225W
  • 1 channel driven, 8Ω bridged mode, 20-20kHz: 790W
  • Harmonic distortion, 80% power, 8Ω at 1kHz: 0.001%
  • Inputs
    • RCA
    • XLR
  • Input sensitivity 200W / 8Ω:
    • 1.15V RMS (RCA)
    • 2.3V RMS (XLR)
  • Signal/Noise ratio (A-wtd) 50W / 8Ω: 110dB
  • Input impedance: 10kΩ
  • Frequency response: 20 - 20kHz +/-0.05dB
  • Mains voltage: 110–120V or 220–240V, 50–60Hz
  • Power consumption (maximum): 1.5kW
  • Power consumption (idle, typical): 90W (Thermal dissipation approx. 340 BTU/hour)
  • Power consumption (standby): <0.5W
  • Dimensions W x D x H (including feet, control knob and speaker terminals): 17.32" x 17" x 7.08"
  • Weight (net): 36.36 lbs

What's In The Box

  • PA240 Amplifier
  • Power cable
