Specifications
Specifications
- Power Output @ 14.4V, 4Ω stereo, <10% THD+N: 25 watts x 4
- Power Output @ 14.4V, 2Ω stereo, <10% THD+N: 38 watts x 4
- Frequency Response: 20Hz - 20kHz
- Signal-to-Noise Ratio: 100dB
- RCA Outputs:
- Pre-amp Outputs: Front, Rear, Subwoofer, Zone2
- Line-Out Level: 4V
- Outer Trim Ring Dimensions: 3.5" x 5.5"
- Protrusion from Mounting Surface: 1-1/8"
- Mounting Depth: 4-3/4"
- Mounting Hole Diameter: 3"
- Mounting Panel Thickness Range: Any
- IP Rating: IP66
- AUX Input Sensitivity: 500mV
- USB (Playback, Charging, Compatible File System): MP2, MP3, WMA, WAV16, FLAC16, DC 5V, 1 AMP, FAT32
- BT Range: 30 ft
